Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S
SUS304 stainless variant (-S)The AirTAC Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S is a genuine branch y for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeBranch Y
- SeriesPYB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S
The PYB1001-S is an AirTAC PYB branch Y, a one-touch fitting that splits a single 10 mm tube supply into two lines, both gripped by the same push-in chuck. The male stud carries a 1/8in PT thread that arrives with sealant pre-applied, so it seals into the port on the first few turns. To connect, push the tube home until it seats; the stainless spring gasket and chuck grip it, and pressing the release ring frees it again.
This -S version keeps the PBT body of the standard PYB but the threaded stud is SUS304, so the connection into a corroded or stainless manifold stays sound where a plain brass stud would degrade. Ratings are unchanged from the standard resin line: 0-1.0 MPa working, 1.5 MPa proof, -750 mmHg vacuum, -20 to +70 C. Note that at -20 C the soft nylon or PU tubing is usually the first limit, not the fitting.
Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S Technical Specifications
| Model | Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S |
|---|---|
| Type | Branch Y |
| Series | PYB |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S
| PYB | Branch Y. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S Is Used
Twin-wash nozzles on a lab glassware washer
One 1/8in PT tap on the washer manifold splits through the SUS304 stud into two Dia 10 tube runs feeding parallel rinse nozzles, with the Y angle keeping the tubes routed flush along the cabinet wall instead of one hard 90 deg turn.
Corrosion-prone plating line actuator supply
On a pick-and-place arm above an acid plating bath, the SUS304 stud resists attack at the manifold port while the PBT body carries 0-1.0 MPa air to a single Dia 10 leg feeding two clamp cylinders.
Dual air knives on a bottle rinsing conveyor
A Dia 10 supply running the length of a rinse conveyor branches at the Y into two equal Dia 10 lines, one per air knife station, so both knives see a split of the same feed without extra fittings in the path.
Is the Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S the Right Part?
On the PYB ladder at 1/8in PT, Dia 10 is the top of the rung: the next size down is Dia 8 (PYB801), and there is no Dia 12 in 1/8in. If you are feeding two Dia 10 lines from a manifold, step up to the same tube on a 1/4in thread (PYB1002) so the port has more thread engagement and the stud is stiffer. The Y angle is the point of this shape: it sends both branches along the tube run instead of at right angles, so no 90 deg bends in the tubing that rob effective bore and add stress on the push-in collar.
Check that both tube legs are exactly Dia 10; a 5/16in (7.9 mm) tube will slide in but the chuck cannot seal it reliably. For a run that has to turn rather than split, the PE union tee or PV union elbow is the wrong-shape check - the Y exists specifically for angled splits.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PYB Y-Type Threaded Tee Fitting PYB1001-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), proof pressure 1.5 MPa, vacuum to -750 mmHg (10 Torr), temperature -20 to +70 C. This SKU accepts Dia 10 mm tube on all three legs and a 1/8in PT male thread on the stud, which arrives with sealant. The stainless -S option makes the stud SUS304 while the body stays PBT; pressure and temperature figures are identical to the standard PYB1001.
No. Every one-touch port on this fitting is bored and gasketed for exactly Dia 10 mm soft nylon or polyurethane tube. An off-size tube can seat but the spring gasket cannot seal on the correct surface, which is the usual cause of a slow weep at a pushed-in joint. If you need Dia 8 or Dia 12 branches, use the PYB different-diameter union Y family or a PG reducer before the split.
