Airtac PYB Y-Type Threaded Tee Fitting PYB1202
The AirTAC Airtac PYB Y-Type Threaded Tee Fitting PYB1202 is a genuine branch y for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeBranch Y
- SeriesPYB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PYB Y-Type Threaded Tee Fitting PYB1202
The PYB1202 is an AirTAC PYB branch Y: a male-threaded one-touch fitting that takes a single 1/4in PT port and splits it into two Dia 12 mm tube legs set at a Y angle. Push each tube straight into its chuck and the stainless spring gasket grips it for a sealed joint; press the POM release ring and the tube slides straight back out for rework or re-routing.
It runs on AirTAC's resin spec profile: 0 to 1.0 MPa working pressure (0-10 kgf/cm2), vacuum down to -750 mmHg (10 Torr), 1.5 MPa proof pressure and -20 to +70 C. The body is PBT on a brass stud, the thread arrives pre-coated with sealant, and the standard colour is grey (a D suffix would give black). With 12 mm bore on both legs, this is the large-end member of the PYB ladder for main air distribution.
Airtac PYB Y-Type Threaded Tee Fitting PYB1202 Technical Specifications
| Model | Airtac PYB Y-Type Threaded Tee Fitting PYB1202 |
|---|---|
| Type | Branch Y |
| Series | PYB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PYB Y-Type Threaded Tee Fitting PYB1202
| PYB | Branch Y. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PYB Y-Type Threaded Tee Fitting PYB1202 Is Used
Robot gripper supply split
On a robotic pick-and-place wrist, a single 1/4in drop from the end-of-arm valve block splits at the PYB1202 into two Dia 12 legs feeding parallel pneumatic grippers, with no extra tee body to snag in the cage.
Palletiser clamp manifold branch
A palletiser's clamp beam carries one 1/4in PT run; the PYB1202 branches it into two 12 mm lines serving the side-clamp and hold-down cylinders, both legs releasing from the same fitting when the beam is rebuilt.
Twin blow-off nozzles on a filling line
A bottled-water line uses one 1/4in feed to drive two air knives either side of the conveyor; the PYB1202 splits the supply at the frame so each Dia 12 leg reaches its nozzle without a junction box.
Is the Airtac PYB Y-Type Threaded Tee Fitting PYB1202 the Right Part?
At a 1/4in PT thread, Dia 12 is the largest tube the PYB accepts - there is no size above it on this port. Step down instead to PYB1002 (Dia 10 tube) if your actuators are on 10 mm line; the smaller bore suits lighter-consuming legs but starves big cylinders sooner. If the port itself is 3/8in, the same 12 mm tube is available as PYB1203, which moves the choice onto the thread rather than the bore.
Match the 1/4in PT male stud to the actual port spec before ordering, and remember tube OD must match exactly: a Dia 12 Y will not seal on 1/2in or 10 mm tube. If the two legs need different bores, the different-diameter series (PYW) is the correct route, not this fitting.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PYB Y-Type Threaded Tee Fitting PYB1202 FAQ
Working pressure 0 to 1.0 MPa (0-10 kgf/cm2), negative pressure to -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. The part is a Dia 12 mm one-touch branch Y with a 1/4in PT male thread, grey PBT body on a brass stud, with thread sealant pre-applied. Use soft nylon or polyurethane tube sized exactly Dia 12.
No. Both legs of the PYB1202 grip Dia 12 mm tube only - the chuck set is a single size, and tube OD must match the fitting exactly or it will not seal or release properly. For a branch that steps down to a smaller bore, use a different-diameter Y such as the PYW series, which carries both sizes in its code.
