Airtac PZB Cross Threaded Fitting PZB1002D-S
SUS304 stainless variant (-S)The AirTAC Airtac PZB Cross Threaded Fitting PZB1002D-S is a genuine threaded cross for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeThreaded cross
- SeriesPZB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PZB Cross Threaded Fitting PZB1002D-S
The PZB1002D-S is an AirTAC PZB threaded cross in the SUS304-stud variant: a four-way one-touch junction with a 1/4 in PT male thread on one leg and three push-in sockets for Dia 10 mm soft nylon or polyurethane tube. Push each tube home and the internal chuck grips it; press the POM release ring and the chuck lets go. Worth knowing before you shortlist: the PZB ladder has no M5 and no Dia 4 entry at all - the family starts at 1/8 in with Dia 6 tube, so this cross already sits in the upper half of the range.
It runs the standard resin one-touch profile: 0-1.0 MPa working pressure, -750 mmHg (10 Torr) vacuum, 1.5 MPa proof pressure and -20 to +70 C. These are the resin figures, not the 0.9 MPa / 150 C metal BP line. The trailing -S fits a SUS304 stud where the fitting screws into the port; the cross body itself stays PBT, with POM release rings, an aluminium-alloy guide, a stainless spring gasket and NBR O-rings. The D in the code marks the black-body version of the standard part.
Airtac PZB Cross Threaded Fitting PZB1002D-S Technical Specifications
| Model | Airtac PZB Cross Threaded Fitting PZB1002D-S |
|---|---|
| Type | Threaded cross |
| Series | PZB |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PZB Cross Threaded Fitting PZB1002D-S
| PZB | Threaded cross. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PZB Cross Threaded Fitting PZB1002D-S Is Used
Washdown line branch junction
Splitting a Dia 10 supply three ways at a chain-lubrication and hold-down station on a meat-processing washdown conveyor, where the SUS304 stud stands up to daily caustic spray at the threaded port.
Plating shop air drops
A 1/4 in PT feed from an acid-fume-exposed plating line riser branching to rinse-nozzle tubes, agitator cylinders and a DI-water ejector, with corrosion resistance concentrated at the metal-to-port interface.
Palletizer gripper manifold
One machine riser thread feeding two vacuum-ejector lines and a tube run to the corner-guide cylinder on a case palletizer, replacing three separate tees with a single compact four-way body.
Is the Airtac PZB Cross Threaded Fitting PZB1002D-S the Right Part?
On the PZB interface table a 1/4 in thread carries Dia 6, 8 and 10 tube, so Dia 10 is the largest bore you can run on a 1/4 in cross. Step down to PZB802 for Dia 8 if the branch feeds smaller actuators; to reach Dia 12 you have to change thread, because Dia 12 never appears on 1/4 in - that means PZB1203 on a 3/8 in port or PZB1204 on 1/2 in. If your port is already 3/8 in and you want to keep Dia 10 tube, PZB1003 is the direct equivalent with a bigger stud. The PT thread arrives with sealant applied, and the tube OD must match the socket exactly - a Dia 10 socket will not grip 8 mm or 12 mm tube.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PZB Cross Threaded Fitting PZB1002D-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), negative pressure down to -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. The fitting joins Dia 10 mm soft nylon or polyurethane tube to a 1/4 in PT male thread, with three push-in sockets and one threaded leg forming the four-way cross. No L/min or Cv figure is published for this family; capacity follows the Dia 10 bore.
Not on this SKU. On the PZB ladder a 1/4 in thread supports only Dia 6, 8 and 10 tube, and Dia 10 is the top of that port. Dia 12 exists only on the 3/8 in (PZB1203) and 1/2 in (PZB1204) versions, so move up a thread size if you need the larger bore. And because tube OD must match exactly, a Dia 10 socket will not seal on 12 mm tube no matter how hard it is pushed in.
