Airtac PZB Cross Threaded Fitting PZB1004
The AirTAC Airtac PZB Cross Threaded Fitting PZB1004 is a genuine threaded cross for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeThreaded cross
- SeriesPZB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PZB Cross Threaded Fitting PZB1004
The PZB1004 is an AirTAC PZB one-touch threaded cross, the four-way fitting that turns a single 1/2in PT male thread into three Dia 10 mm tube take-offs at right angles to each other. Push each soft nylon or polyurethane tube into its port until it bottoms: the stainless spring gasket and chuck grip the tube wall, and the POM release ring lets it go again when you press it in. The 1/2in PT male stud arrives with sealant already applied, so it threads straight into the port.
This is the resin and brass one-touch profile, not the metal BP line: working pressure 0-1.0 MPa, vacuum down to -750 mmHg, proof pressure 1.5 MPa and a temperature window of -20 to +70 C. Body materials are PBT with a brass threaded stud, a POM release button and chuck, aluminium-alloy guide, stainless spring gasket and NBR O-ring. Note that PZB starts at Dia 6 tube and offers no M5 thread, so this cross lives at the larger end of the range.
Airtac PZB Cross Threaded Fitting PZB1004 Technical Specifications
| Model | Airtac PZB Cross Threaded Fitting PZB1004 |
|---|---|
| Type | Threaded cross |
| Series | PZB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PZB Cross Threaded Fitting PZB1004
| PZB | Threaded cross. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PZB Cross Threaded Fitting PZB1004 Is Used
Can-body press air header
Mounted off the 1/2in main drop on a can-stamping press, the PZB1004 splits the supply three ways to feed the clamp, eject and blow-off circuits in Dia 10 hose without extra junction blocks.
Panel-mount valve manifold feed
On a bottling line valve island, the cross takes the 1/2in PT branch off the FRL manifold and hands three Dia 10 lines to upstream pilot and actuation stations side by side.
Palletiser gripper distribution
Where a palletiser head needs simultaneous suction and blow-off legs, the threaded cross divides the Dia 10 feed from the vacuum generator into three equal take-offs at the wrist.
Is the Airtac PZB Cross Threaded Fitting PZB1004 the Right Part?
On the PZB ladder this 1/2in thread carries Dia 8, Dia 10 and Dia 12 tube only. Step down to PZB804 when the branches feed smaller actuators or valves and you want a slimmer cross; step up to PZB1204 when these three legs supply high-consumption cylinders on a main header. At Dia 10 you are on the middle rung, which keeps flow capacity reasonable while still matching the common 10 mm hose used on mid-size air cylinders. If you need a three-way split rather than a four-way cross, the PED male run tee or PYB branch Y in the same sizes is the lighter answer.
Tube OD must match exactly: a Dia 10 one-touch port will not seal reliably on 3/8in or 12 mm tube, so check the hose printed on the wall before ordering. Match the 1/2in PT stud to a port of the same nominal size; on a manifold with tapped branches this is the natural place for a cross because one fitting replaces a tee plus a union.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PZB Cross Threaded Fitting PZB1004 FAQ
It is a PZB one-touch threaded cross for Dia 10 mm tube with a 1/2in PT male thread. Working pressure is 0-1.0 MPa (0-10 kgf/cm2), vacuum to -750 mmHg (10 Torr), proof pressure 1.5 MPa and operating temperature -20 to +70 C. It accepts soft nylon or polyurethane tubing, and the 1/2in stud ships with thread sealant applied.
No. One-touch fittings hold only the exact tube OD they were made for, so the Dia 10 ports of the PZB1004 will not grip 12 mm or 3/8in hose. If your line is 12 mm tube on a 1/2in thread, order the PZB1204; for 8 mm tube on the same thread, the PZB804 is the correct part. Adapters such as the PG different-diameter union can step a branch down afterwards, but the port itself must see matching Dia 10 tube.
