Airtac PZB Cross Threaded Fitting PZB1004-S
SUS304 stainless variant (-S)The AirTAC Airtac PZB Cross Threaded Fitting PZB1004-S is a genuine threaded cross for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeThreaded cross
- SeriesPZB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PZB Cross Threaded Fitting PZB1004-S
The PZB1004-S is an AirTAC PZB one-touch threaded cross: a four-way fitting that joins a 1/2in PT male thread to three Dia 10 mm push-in ports, letting one supply line branch into three outlet circuits from a single screw-in point. On a cross, the thread sits on one axis and the three tube ports sit on the other two, so the fitting also acts as a rigid spacer between tube runs.
Connection is genuinely one-touch: push the soft nylon or PU tube straight into a port until it bottoms on the stainless spring gasket and the POM chuck grips the OD; press the release ring to free it. This SKU carries the -S suffix, which means the stud is SUS304 stainless steel while the body stays PBT. Ratings are unchanged from the standard resin line: 0-1.0 MPa working, 1.5 MPa proof, -750 mmHg vacuum and -20 to +70 C. Threaded ports arrive with sealant applied; no additional tape is needed.
Airtac PZB Cross Threaded Fitting PZB1004-S Technical Specifications
| Model | Airtac PZB Cross Threaded Fitting PZB1004-S |
|---|---|
| Type | Threaded cross |
| Series | PZB |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PZB Cross Threaded Fitting PZB1004-S
| PZB | Threaded cross. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PZB Cross Threaded Fitting PZB1004-S Is Used
Lab automation manifold splitting
On a chemistry analyser or pipetting station, one 1/2in supply off the solenoid bank can be cross-split into three Dia 10 lines feeding separate vacuum ejectors or air knives, all from one threaded port on the frame.
Textile machine air-jet distribution
Looms and spinning frames run banks of small nozzles off a common header; the cross mounts mid-run on the 1/2in PT stud and feeds three 10 mm branch lines to nozzle blocks on either side and below.
Control cabinet pneumatic feedthrough
With the stud passed through a panel cut-out, the cross turns one bulkhead penetration into three push-in take-offs for inside-the-door cylinders and air blast nozzles, keeping the wet side outside the enclosure.
Is the Airtac PZB Cross Threaded Fitting PZB1004-S the Right Part?
On the 1/2in PT row of the PZB ladder the supported tube sizes are Dia 8, 10 and 12, so the PZB804 steps down to 8 mm lines and the PZB1204 steps up to 12 mm. Dropping to Dia 8 saves panel space and suits lighter actuator loads; going to Dia 12 lowers air velocity on long runs or high-consumption headers. Dia 10 in the same thread is also offered as PZB1003 if your port is 3/8in instead of 1/2in.
Tube OD must match exactly: a Dia 10 port will not seal on 3/8in (10 mm is close but the chuck is cut for metric wall thickness and tolerance). A PZB cross is the right shape when you need four connections meeting at one point without a fabricated manifold block; if you only need two tube legs, a PE union tee is the smaller answer.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PZB Cross Threaded Fitting PZB1004-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), proof pressure 1.5 MPa, vacuum down to -750 mmHg (10 Torr), operating temperature -20 to +70 C. This SKU joins Dia 10 mm soft nylon or polyurethane tube to a 1/2in PT male thread. The -S suffix adds a SUS304 stainless stud; every pressure, vacuum and temperature figure is identical to the grey standard version.
On the PZB family the -S option makes the threaded stud SUS304 stainless steel; the cross body remains PBT with POM chucks, an aluminium guide and an NBR seal. It does not re-rate the fitting, so use the standard 0-1.0 MPa / 70 C figures when sizing. Choose it where a corroded stud would seize in a housing - washable machine frames or coastal plant - and match the tube to the temperature limit, since standard PU and nylon tubing, not the fitting, sets the ceiling near 70 C.
