Airtac PZB Cross Threaded Fitting PZB601
The AirTAC Airtac PZB Cross Threaded Fitting PZB601 is a genuine threaded cross for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeThreaded cross
- SeriesPZB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PZB Cross Threaded Fitting PZB601
The PZB601 is an AirTAC PZB threaded cross, a four-way node that screws into a 1/8 in PT female port and lets three Dia 6 mm tubes branch off the fourth leg at 90 degrees to each other. Push each tube into its chuck until it bottoms and the stainless spring gasket grips it; press the release ring to free it. It belongs to the resin and brass one-touch line, so it is rated 0-1.0 MPa (0-10 kgf/cm2), handles -750 mmHg (10 Torr) vacuum, and works from -20 to +70 C on soft nylon or polyurethane tubing.
Two catalogue facts worth knowing before you order: PZB is one of the few prefixes with no M5 option at all, and Dia 4 mm is not offered on this series either, so Dia 6 is genuinely the smallest cross in the family. The 1/8 in thread arrives pre-coated with sealant and pairs only with Dia 6 and Dia 8 tubes on this prefix. The body is PBT on a brass threaded stud, with a POM release button, aluminium-alloy guide, stainless spring gasket and NBR O-ring; grey is standard and a D suffix orders the black version.
Airtac PZB Cross Threaded Fitting PZB601 Technical Specifications
| Model | Airtac PZB Cross Threaded Fitting PZB601 |
|---|---|
| Type | Threaded cross |
| Series | PZB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PZB Cross Threaded Fitting PZB601
| PZB | Threaded cross. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PZB Cross Threaded Fitting PZB601 Is Used
Modular fixture manifolds
On a weld-and-assemble fixture with pneumatic clamps on three faces, a PZB601 at the entry block splits the 1/8 in supply into three Dia 6 mm runs without stacking unions in the cramped fixture frame.
Pick-and-place header plates
Compact pick-and-place modules often need suction lines, a blow-off and a signal-gauge tap at one point; the four legs of this cross feed all three Dia 6 mm circuits from a single 1/8 in port.
Bottling line reject stations
At a bottle-reject puff station, a PZB601 mounted on the frame splits the supply between the reject nozzle, the gate cylinder and a sensor purge line, all in Dia 6 mm nylon tube.
Is the Airtac PZB Cross Threaded Fitting PZB601 the Right Part?
PZB601 sits at the bottom of the cross ladder: there is no Dia 4 PZB below it, so if you step down you are really changing shape - a PYB branch Y (PYB601) covers three-way splitting at the same 6 mm and 1/8 in size. Stepping up in bore gives the PZB801, and if 1/8 in is too small for the flow your circuit needs at a shared node, the PZB602 keeps the Dia 6 tube but moves to a 1/4 in PT thread. Remember the tube must match exactly: a Dia 6 chuck will not seal on 1/4 in (6.35 mm) imperial hose, so re-terminate the line rather than forcing it.
Choose a cross over a tee only when you truly need four connections in one body - each extra leg adds a potential leak path and a push-fit to maintain. If your fourth connection is a plug instead, a PED male run tee with a PP plug in the spare port does the same job with more future flexibility.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PZB Cross Threaded Fitting PZB601 FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2), negative pressure -750 mmHg (10 Torr), proof pressure 1.5 MPa, operating temperature -20 to +70 C. It is a threaded cross for Dia 6 mm soft nylon or polyurethane tube with a 1/8 in PT male thread, supplied with sealant on the thread. These are the resin and brass one-touch ratings; the higher-temperature 150 C figures apply only to the separate BPC metal family.
No on both counts. AirTAC makes no M5 version of the PZB series, and Dia 4 mm is not offered on this prefix, so Dia 6 mm is the smallest cross available. For an M5 four-way arrangement you would have to build it from other prefixes, for example a PEB601-M5 male branch tee plus a PE601 union tee downstream.
