Airtac PZB Cross Threaded Fitting PZB602-S
SUS304 stainless variant (-S)The AirTAC Airtac PZB Cross Threaded Fitting PZB602-S is a genuine threaded cross for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeThreaded cross
- SeriesPZB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PZB Cross Threaded Fitting PZB602-S
The PZB602-S is an AirTAC PZB threaded cross, the four-way node of the one-touch resin family: a single 1/4in PT male thread on one side and three Dia 6 mm push-in ports radiating from the same centre. Push each 6 mm soft nylon or polyurethane tube home and the internal chuck grips it under spring load; press the POM release ring square to the port and the tube frees off again. It runs the standard resin spec: 0-1.0 MPa working pressure, -750 mmHg vacuum, 1.5 MPa proof pressure, and -20 to +70 C, with NBR O-rings sealing every chuck. The male thread arrives with sealant already applied, so it screws straight into a PT-tapped port.
The -S suffix changes one thing and one thing only on this part: the threaded stud is SUS304 stainless steel. The cross body stays PBT with an aluminium-alloy guide and POM button, and every pressure, vacuum and temperature figure is identical to the grey standard version. If you need an all-304 body, that is the PC-S straight connector, not the PZB.
Airtac PZB Cross Threaded Fitting PZB602-S Technical Specifications
| Model | Airtac PZB Cross Threaded Fitting PZB602-S |
|---|---|
| Type | Threaded cross |
| Series | PZB |
| Connection | Push-in one-touch |
| Body material | Stainless steel 304 (-S variant) |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. Stainless (-S): SUS304 in place of brass - a solid SUS304 body on the PC and POC straight connectors, and a PBT body with a SUS304 stud on the elbow, tee and branch shapes. Working pressure, proof pressure and temperature are unchanged from the standard version. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PZB Cross Threaded Fitting PZB602-S
| PZB | Threaded cross. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
| -S | Stainless-steel body. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PZB Cross Threaded Fitting PZB602-S Is Used
PCB pick-and-place head
A 1/4in port on the gantry manifold splits to three Dia 6 vacuum lines feeding individual suction cups, so one threaded outlet replaces three tee joints and their leak points.
Bottle-rinse blow-off station
Three Dia 6 blow-off nozzles on a bottling line fed from a single 1/4in PT tapping in the stainless manifold header, keeping the pipework count down in the splash zone.
Lab sample-handler clamp circuit
A laboratory auto-sampler clamping a 6 mm actuator pair plus a purge line from one 1/4in port, where the SUS304 stud shrugs off occasional reagent spills at the thread.
Is the Airtac PZB Cross Threaded Fitting PZB602-S the Right Part?
On the 1/4in rung of the PZB ladder, Dia 6 is the smallest tube made; the row above it is 8 and 10 mm only, so PZB802 is the single step-up and there is no smaller sibling. PZB also has no Dia 4 version at any thread, and no M5 option at all: the threaded cross range starts at 1/8in. If you need Dia 6 on a tighter port, PZB601 is the same cross on 1/8in; PZB603 moves it to 3/8in. Where the node has to pass through a panel wall instead of screwing into one, the PM bulkhead union or PLM bulkhead male elbow is the right shape instead. Whichever you pick, the port must be Dia 6 exactly - this chuck will not seal on 1/4in (6.35 mm) tube.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PZB Cross Threaded Fitting PZB602-S FAQ
Working pressure 0-1.0 MPa (0-10 kgf/cm2); vacuum to -750 mmHg (10 Torr); proof pressure 1.5 MPa; temperature -20 to +70 C. It joins Dia 6 mm soft nylon or polyurethane tube to a 1/4in PT male thread, with three Dia 6 push-in outlets. The stud is SUS304; the body is PBT. Ratings are identical to the non-stainless PZB602.
No. On the PZB family the -S suffix swaps only the stud to SUS304 stainless steel. The body remains PBT, and the 1.0 MPa working pressure, 1.5 MPa proof pressure and -20 to +70 C range are unchanged. Never re-rate a stainless one-touch part upward, and at elevated temperatures check the tube's rating first - the tubing, not the fitting, usually gives way first.
