Airtac PZB Cross Threaded Fitting PZB603
The AirTAC Airtac PZB Cross Threaded Fitting PZB603 is a genuine threaded cross for push-in tube connection, rated 0 - 1.0 MPa (0 - 10 kgf/cm2) with a 1.5 MPa proof pressure.
- TypeThreaded cross
- SeriesPZB
- Working pressure0 - 1.0 MPa (0 - 10 kgf/cm2)
- Proof pressure1.5 MPa
- Temperature-20 to +70 °C
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PZB Cross Threaded Fitting PZB603
The PZB603 is an AirTAC one-touch threaded cross: a four-way node with one male 3/8in PT thread on its inlet leg and three Dia 6mm push-in ports on the remaining legs. Instead of chaining tees and connectors, you thread one part into a port or manifold and branch three tube lines straight off it. Each push-in port works the same way: push the tube fully home and the internal chuck grips the OD, then press the release ring to let it go.
This is the resin/brass profile, not the metal line: working pressure 0-1.0 MPa (0-10 kgf/cm2), vacuum to -750 mmHg, proof pressure 1.5 MPa, and a temperature window of -20 to +70 C. The release button and chuck are POM, the threaded body is PBT on a brass stud, with a stainless spring gasket and NBR O-ring doing the tube seal. The 3/8in thread arrives with sealant already applied, so it is ready to screw straight into a PT port.
Airtac PZB Cross Threaded Fitting PZB603 Technical Specifications
| Model | Airtac PZB Cross Threaded Fitting PZB603 |
|---|---|
| Type | Threaded cross |
| Series | PZB |
| Connection | Push-in one-touch |
| Working pressure | 0 - 1.0 MPa (0 - 10 kgf/cm2) |
|---|---|
| Negative pressure | -750 mmHg (10 Torr) |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Applicable tubing | Soft nylon or polyurethane tube |
| Thread standard | PT (Rc tapered) unless the code says otherwise |
POM release button and chuck, aluminium-alloy guide, stainless spring gasket, NBR O-ring; body brass or PBT depending on the part. AirTAC publishes flow as a characteristic curve rather than a single figure, so no L/min value is listed.
Model Code: Airtac PZB Cross Threaded Fitting PZB603
| PZB | Threaded cross. |
|---|---|
| 4 / 6 / 8 / 10 / 12 | Tube outside diameter in mm (3.2 mm exists on the mini series). |
| M5 / 01 / 02 / 03 / 04 | Thread: M5x0.8, 1/8", 1/4", 3/8", 1/2" (M3 on the mini series). |
| D | Black. Blank = grey. |
Fitting & Sealing Notes
- check Cut the tube square and clean before pushing it home, or the seal will leak.
- check Push until it stops, then pull back to check the chuck has gripped.
- check To release, press the collet ring fully in and pull the tube out.
- check Threaded parts arrive with sealant on the thread; M5 sizes use a sealing gasket.
- check Match the tube OD exactly - a 6 mm fitting will not hold 1/4" tube.
Where the Airtac PZB Cross Threaded Fitting PZB603 Is Used
Bottling monobloc clamp circuit
A single 3/8in manifold port on a rotary filler can feed three Dia 6 clamp or guide-cylinder lines at once, replacing a stack of elbows and unions inside a crowded guard.
Screen-printing carousel stations
Printing carousels run repeated identical pneumatic stations. A PZB603 at each station's supply point splits one threaded feed into three Dia 6 squeegee or flood-bar lines without extra threaded joints.
Dispensing manifold in lab automation
Compact dispensing cells often need one regulated supply split to three small Dia 6 actuator or pump lines; the cross does it in one screw-in part and frees the rest of the back panel.
Is the Airtac PZB Cross Threaded Fitting PZB603 the Right Part?
Within the PZB ladder, Dia 6 is the smallest tube this cross is made in - there is no Dia 4 version of the threaded cross, so there is nothing to step down to. Stepping up one size gives the PZB803, which takes Dia 8 tube and the same 3/8in thread; that buys you a larger bore for circuits where the Dia 6 lines feed anything flow-hungry. On the thread side, the PZB602 gives you Dia 6 on a 1/4in port instead, and note that a 1/2in threaded cross only exists from Dia 8 upward.
Whatever you choose, the tube must match the port exactly: a Dia 6 port will not securely hold 1/4in (6.35mm) tube even though the difference looks trivial. If you only need two branch lines rather than three, a PEB or PED branch tee is the leaner part; keep the cross for genuine four-way splits.
Quick checklist
- ✓ Tube outside diameter matches exactly
- ✓ Thread size and standard match the port
- ✓ Working pressure within 0 - 1.0 MPa (0 - 10 kgf/cm2)
- ✓ Temperature within -20 to +70 °C
Airtac PZB Cross Threaded Fitting PZB603 FAQ
It is an AirTAC PZB one-touch threaded cross with three Dia 6mm push-in tube ports and one male 3/8in PT thread. Working pressure is 0-1.0 MPa (0-10 kgf/cm2), vacuum rating -750 mmHg, proof pressure 1.5 MPa, and operating temperature -20 to +70 C. It is intended for soft nylon or polyurethane tubing.
Not directly. In the PZB range the 1/2in thread is only produced from Dia 8 tube upward, so a Dia 6 body on a 1/2in thread does not exist in the catalogue. Use the PZB804 with Dia 8 tube, step to the PZB602 on a 1/4in port, or fit a reducing bush in the port first - the tube size must match the push-in port exactly either way.
