Airtac SI50 Standard Cylinder SI50X100SH
2. Piston features a durable Y-type axial seal with self-compensating function, providing extended service life and low friction resistance
3. Aluminum tube with crisscross reinforcement design and anodized tie rods for enhanced corrosion resistance
4. Adjustable cushioning for smooth operation
5. Multiple configurations available with comprehensive cylinder variants and mounting accessories for flexible system integration
Category: Standard Cylinders | Brand: AirTAC | Series: SI50
AirTAC SI50X100SH Standard Cylinder Technical Details
- Model: SI50X100SH
- Type: ISO 6432 compliant single-acting spring return cylinder
- Bore size: Ø50 mm (±0.13mm manufacturing tolerance)
- Stroke: 100 mm (adjustable cushioning ±10%)
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)/150℃(option with FKM seals)
- Cushioning type: Air cushion adjustable with rubber buffers
- Port size: G1/8 (ISO 228-1 standard)
- Piston rod thread: M16×1.5 (10.9 grade alloy steel)
- Tube material: Aluminum alloy 6063-T5 with hard anodized surface
- Rod material: Chrome-plated carbon steel (S45C)
- Seal material: NBR standard (option for Polyurethane in high-speed applications)
- Mounting type: SH series - Double female threaded ends (M16×1.5)
- Weight: 2.85 kg (without accessories)
- Dimensions:
- Total length: 248 mm (at full retraction)
- Stroke length: 100 mm
- Mounting distance: 33 mm between thread centers
- Rod end thread length: 20 mm
- Body diameter: Ø50 mm (±0.2mm)
- Max theoretical force: 1963N at 0.63MPa (push side)
- Air consumption: 196.3 cm³/stroke at 0.5MPa
- Lubrication: Pre-lubricated (relubrication interval: 2000km operation)
High-precision industrial cylinder featuring wear-resistant chromium-plated rod and integrated cushioning system. The T-slot mounting design enables 360° adjustable positioning. Optimized for 1 million cycle durability in ISO 8573-1:2010 Class 3 air quality conditions. Includes magnetic piston (D-M9BW sensor compatible) for position feedback.
- Press machine ejection systems
- Plastic injection molding clamp units
- CNC fixture positioning mechanisms
- Conveyor gate actuators
- Automotive welding jig operation
Installation protocol:
Apply 32-38N·m torque during mounting. Maintain 0.5mm minimum alignment tolerance.
For vertical mounting, use rod-down orientation to prevent seal wear. Lubricate with
ISO VG32 hydraulic oil if operated below -10℃.
| Property | Property Value |
|---|---|
| sku | SI50X100SH |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
