Airtac SI50 Standard Cylinder SI50X100SN
2. Piston features a durable Y-type axial seal with self-compensating function, providing extended service life and low friction resistance
3. Aluminum tube with crisscross reinforcement design and anodized tie rods for enhanced corrosion resistance
4. Adjustable cushioning for smooth operation
5. Multiple configurations available with comprehensive cylinder variants and mounting accessories for flexible system integration
Category: Standard Cylinders | Brand: AirTAC | Series: SI50
AirTAC SI50X100SN Standard Cylinder Technical Details
- Model: SI50X100SN
- Bore size: Ø50 mm
- Stroke: 100 mm (±0.5 mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (Use ISO VG32 oil if relubrication needed)
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated stainless steel (SUS304)
- End caps: Die-cast zinc alloy with nickel plating
- Weight: 2.7 kg (with rod)
- Dimensions:
- Extended length: 226 mm
- Retracted length: 126 mm
- Body diameter: Ø56 mm
- Mounting hole spacing: 40×40 mm (standard MF1 pattern)
- ISO standard: 6432
- Protection class: IP54 (standard), IP67 optional
The SI50X100SN combines high thrust force (785N at 0.4MPa) with precision alignment, featuring wear-resistant dual-seal design (NBR + PU). Its anti-rotation guide grooves ensure stable linear motion, while the chrome-plated rod withstands 5,000km stroke life in standard conditions. Requires 5μm filtered air with <3% oil content.
- Press machine ejection systems
- Automated welding fixture clamping
- CNC machine tool chip conveyors
- Plastic injection molding ejectors
- Automotive assembly line positioning
Mounting advice:
Use M6×25 mounting bolts (8.8 grade min.) with parallelism ≤0.2mm/m.
For vertical installations, add rod-end support to prevent side load.
Perform stroke test before pressure application.
| Property | Property Value |
|---|---|
| sku | SI50X100SN |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
