Airtac SI50 Standard Cylinder SI50X1050
2. Piston features a durable Y-type axial seal with self-compensating function, providing extended service life and low friction resistance
3. Aluminum tube with crisscross reinforcement design and anodized tie rods for enhanced corrosion resistance
4. Adjustable cushioning for smooth operation
5. Multiple configurations available with comprehensive cylinder variants and mounting accessories for flexible system integration
Category: Standard Cylinders | Brand: AirTAC | Series: SI50
AirTAC SI50X1050 Standard Cylinder Specifications
- Model: SI50X1050
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: 50 mm
- Stroke: 1050 mm
- Operating pressure: 0.05–1.0 MPa
- Port size: M5x0.8 (G1/8 optional)
- Cushioning: Adjustable rubber buffer (both ends)
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile Butadiene Rubber)
- Mounting style: Basic type (optional front flange/rear foot)
- Weight: 4.8 kg (without rod end accessories)
- Dimensions:
- Body diameter: 50 mm
- Extended length: 1340 mm (stroke + cylinder body)
- Retracted length: 290 mm
- Rod diameter: 20 mm
- Protection rating: IP65 (dust-tight & water jet resistant)
High-precision long-stroke pneumatic cylinder with chromium-plated piston rod (HRC 45-50 hardness). Features anti-rotation guide for stable linear motion and wear-resistant aluminum alloy body. Designed for heavy-load applications requiring extended linear displacement with ≤0.5 mm/m straightness accuracy. Requires 40μm filtered lubricated air (ISO 8573-1).
- Automated packaging line material pushers
- Automotive welding fixture positioning
- Paper processing machinery actuators
- Elevator door operating mechanisms
- Metal stamping machine ejectors
Installation note:
Maintain 0.1-0.3 mm/m alignment tolerance during mounting. Apply ISO VG32 hydraulic oil
lubrication monthly. Avoid side load exceeding 30N. For vertical mounting, use auxiliary
guide mechanisms when stroke/rod diameter ratio >50:1.
| Property | Property Value |
|---|---|
| sku | SI50X1050 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 1050mm |
