Airtac SU32~50 Standard Cylinder SU32X100SLB
$50.21
Regular price
$57.71
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SU32X100SLB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with AirTAC Enterprise Standard pneumatic cylinder specifications;
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
Installation tips:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
Lubricate every 3 months with ISO VG32 hydraulic oil. Avoid side load exceeding 15N.
Critical note:
Use air filtration ≤25μm to prevent seal damage. Maximum permissible lateral
misalignment: 0.3° (use alignment couplers for non-axial loads).
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X100SLB Standard Cylinder Specifications
- Model: SU32X100SLB (SU32~50 Series)
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: 32 mm
- Stroke: 100 mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (G1/8 optional)
- Mounting: Standard ISO 15552 foot and front flange
- Rod thread: M10x1.25 external
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (Nitrile) standard, optional FKM/Viton
- Weight: 1.25 kg (with rod), 0.98 kg (body only)
- Dimensions: 206mm(L) × 50mm(W) × 50mm(H) (retracted length)
- Max thrust: 256N at 0.63MPa
- Speed range: 50–750 mm/s
- IP rating: IP54 (standard), IP67 with optional wiper
A precision-engineered compact cylinder featuring wear-resistant chromium coating and dual anti-rotation design. The self-lubricating guide bush minimizes stick-slip effect during low-speed operation. Integrated magnetic slot (SLB variant) enables position feedback when used with sensors.
Typical Applications:
- Automated assembly line clamping mechanisms
- Printing press paper feed systems
- CNC machine tool door interlocks
- Pharmaceutical blister packaging machines
- Solar panel cleaning robot actuators
Installation tips:
Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body.
Lubricate every 3 months with ISO VG32 hydraulic oil. Avoid side load exceeding 15N.
Critical note:
Use air filtration ≤25μm to prevent seal damage. Maximum permissible lateral
misalignment: 0.3° (use alignment couplers for non-axial loads).
| Property | Property Value |
|---|---|
| sku | SU32X100SLB |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
