Airtac SU32~50 Standard Cylinder SU32X100SN
$46.95
Regular price
$54.45
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SU32X100SN
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with AirTAC Enterprise Standard pneumatic cylinder specifications;
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
Installation Guidelines:
Maintain 0.5mm alignment tolerance during mounting. For vertical installations exceeding 50° angle,
use rod-end support brackets (Accessory code: BR-32). Lubricate every 3,000km stroke distance or 6 months.
2. Features proprietary asymmetric bidirectional piston seal configuration with integrated oil reservoir for compact dimensions;
3. Rodless design with corrosion-resistant octagonal aluminum tube profile (T-slot structure);
4. Superior stroke length compactness compared to ISO 15552 standard cylinders of equivalent bore sizes;
5. Integrated adjustable cushioning mechanism ensures smooth transition at stroke ends;
6. Full compatibility with SC series cylinder mounting accessories;
7. Optional high-temperature seals enable reliable operation at 150°C ambient conditions.
Category: Standard Cylinders | Brand: AirTAC | Series: SU32~50
AirTAC SU32X100SN Standard Cylinder Technical Specifications
- Model Series: SU32~50 (Standard Cylinder Range)
- Bore Size: 32mm (±0.1mm precision honing)
- Stroke: 100mm (Customizable 25-500mm)
- Operating Pressure: 0.05-1.0 MPa (ISO 6431 compliant)
- Piston Speed: 50-750 mm/s (Lubricated condition)
- Cushioning: Adjustable elastic cushion (Both ends)
- Port Size: G1/8 (NPT1/8 optional)
- Mounting Type: SN series (Front flange + rear foot)
- Rod Material: Chrome-plated carbon steel (4-45HRC)
- Tubing Material: Aluminum alloy (Anodized surface)
- Seal Type: NBR + PU combination seals
- Temperature Range: -20℃ to 80℃ (Dry air required below 0℃)
- Weight: 1.25kg (±5% tolerance)
- Dimensions:
- Extended Length: 224mm (Stroke 100 + Base 124)
- Retracted Length: 124mm
- Body Diameter: 50mm
- Mounting Hole Spacing: 50×50mm (Front flange)
- ISO Standard: 6431/DIN ISO 6432
- Protection Class: IP54 (Standard sealing)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if needed)
A workhorse cylinder with optimized air consumption (3.5L/min @6bar) and anti-rotation rod design. Features wear-resistant guide bushings and corrosion-resistant plating. Optional magnetic piston version (SU32X100SN-M9) for position sensing. Requires 40μm filtered air with dew point -25℃ below ambient.
Industrial Applications:
- Clamping fixtures in CNC machining centers
- Conveyor gate actuators in packaging lines
- Material ejection in injection molding
- Paper feed mechanisms in printing equipment
- Valve switching in water treatment plants
Installation Guidelines:
Maintain 0.5mm alignment tolerance during mounting. For vertical installations exceeding 50° angle,
use rod-end support brackets (Accessory code: BR-32). Lubricate every 3,000km stroke distance or 6 months.
| Property | Property Value |
|---|---|
| sku | SU32X100SN |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
