This model is discontinued
AirTAC has phased out the SU series. You can still order this code here: we ship the direct replacement SAUJ100X100-20S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAU replacement uses the same profile body, bore, stroke, force and SC-series mounting. It moves to the current CMSG / DMSG / EMSG sensor switches (the SU used CS1-B / DS1-B) and adds the SAUF valve-integrated option.
Airtac SUJ Adjustable Cylinder SUJ100X100-20S
The AirTAC Airtac SUJ Adjustable Cylinder SUJ100X100-20S is a double-acting profile-type standard cylinder with a Ø100mm bore and 100mm stroke, 1/2" air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAUJ100X100-20S, which matches its bore, stroke, force and mounting.
- BoreØ100 mm
- Stroke100 mm
- Port size1/2"
- Acting typeDouble acting
- Rod threadM20×1.5
- StatusDiscontinued → SAUJ100X100-20S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SUJ Adjustable Cylinder SUJ100X100-20S
The AirTAC SUJ100X100-20S is a discontinued double-acting double-rod profile cylinder with an external stop screw that lets you trim the extend stroke by up to 20 mm on-site, yielding a usable 80 to 100 mm stroke. The direct replacement is the SAUJ100X100-20S, matching the bore, force, and mounting.
The compact profile barrel is shorter than an ISO 15552 cylinder of the same bore. Equipped with a piston magnet (-S), this unit originally used legacy CS1-B/DS1-B switches, whereas the current SAUJ replacement utilizes CMSG/DMSG/EMSG sensors. Remember that the stop screw sets the end position but is not a load lock; use an external rod lock for held loads.
Airtac SUJ Adjustable Cylinder SUJ100X100-20S Technical Specifications
| Model | Airtac SUJ Adjustable Cylinder SUJ100X100-20S |
|---|---|
| Series | SU profile-type cylinder (discontinued) |
| Replacement | SAUJ100X100-20S |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/2" |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SU datasheet (now discontinued). The SAUJ100X100-20S carries the same ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
The SAUJ100X100-20S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SUJ Adjustable Cylinder SUJ100X100-20S
| SU | Profile-type standard cylinder (discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SU-family variants: SUD (double rod), SUJ (adjustable stroke) — each maps to its SAU equivalent (SUD→SAUD, SUJ→SAUJ). The current SAU line adds the SAUF valve-integrated option.
Where the Airtac SUJ Adjustable Cylinder SUJ100X100-20S Is Used
Press Fit Tuning
Allows operators to dial in the exact 80 to 100 mm extend position on-site for pressing bearings without machining hard stops.
Variable Length Diverter
Adjusts the extend stroke by up to 20 mm to accommodate different package sizes on a packaging line diverter arm.
Adjustable End Stop
Provides a field-tunable end position for lifting varying pallet heights where a fixed 100 mm stroke would overshoot.
Replacing the Airtac SUJ Adjustable Cylinder SUJ100X100-20S with the SAUJ100X100-20S
To replace the discontinued SUJ100X100-20S, order the direct replacement SAUJ100X100-20S, which preserves the 100 mm bore, 100 mm nominal stroke, 20 mm adjust window, 1/2 inch port, and FA/LB mounting. Choose the 20 mm adjust window if you need precise on-site end-position tuning between 80 and 100 mm. Because this is an -S model, you must upgrade your position sensing from legacy CS1-B/DS1-B to current CMSG/DMSG/EMSG switches. For strokes of 300 mm or longer, carefully verify side-load limits to prevent guide wear.
Replacement checklist
- ✓ Same bore / stroke → SAUJ100X100-20S
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S): sensor family CS1-B → CMSG
- ✓ Mounting reused (FA/FB/CA/CB/LB)
- ✓ Need a built-in valve? → SAUF
Airtac SUJ Adjustable Cylinder SUJ100X100-20S FAQ
Yes, the SUJ100X100-20S is discontinued. The direct replacement is the SAUJ100X100-20S, which matches the 100 mm bore, 100 mm stroke, 20 mm adjust window, 1/2 inch port, and FA/LB mounting. You must upgrade the position sensors from legacy CS1-B/DS1-B to current CMSG/DMSG/EMSG switches.
The double-acting double-rod cylinder pushes 3927 N and pulls 3681 N at 0.5 MPa, pushing 5497 N at 0.7 MPa and 7068 N at 0.9 MPa, with a theoretical max of 801 kgf at 1.0 MPa. The external stop screw provides a 20 mm adjust window, allowing you to trim the extend stroke from the 100 mm maximum down to 80 mm. The stop sets end position and is not a load lock.
