Airtac SUJ Adjustable Cylinder SUJ100X110-50
$155.62
Regular price
$163.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SUJ100X110-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with in-house enterprise-standard cylinder specifications;
2. Features specially profiled bidirectional piston sealing structure with compact dimensions and integrated oil reservoir design;
3. Constructed with reinforced octagonal aluminum tubing, rodless configuration demonstrating enhanced corrosion resistance;
4. Maintains more compact length compared to ISO 15552 standard cylinders at equivalent bore sizes;
5. Incorporates adjustable cushioning mechanism for smooth stroke termination;
6. Mounting accessories fully compatible with SC series cylinder components;
7. Utilizes high-temperature resistant seals ensuring reliable operation at 150°C ambient conditions.
Category: Standard Cylinders, Brand: AIRTAC, Series: SUJ
Operation guidance:
Always loosen both lock nuts before stroke adjustment. After setting desired stroke length,
tighten nuts sequentially (inner nut first) to 3.5±0.5 N·m torque. Lubricate adjustment threads
monthly with ISO VG32 hydraulic oil.
Critical note:
Avoid side-load forces exceeding 150N. Use floating joints when lateral
misalignment exceeds 0.5°. Maximum lateral play tolerance: ±1.2° angular deflection.
2. Features specially profiled bidirectional piston sealing structure with compact dimensions and integrated oil reservoir design;
3. Constructed with reinforced octagonal aluminum tubing, rodless configuration demonstrating enhanced corrosion resistance;
4. Maintains more compact length compared to ISO 15552 standard cylinders at equivalent bore sizes;
5. Incorporates adjustable cushioning mechanism for smooth stroke termination;
6. Mounting accessories fully compatible with SC series cylinder components;
7. Utilizes high-temperature resistant seals ensuring reliable operation at 150°C ambient conditions.
Category: Standard Cylinders, Brand: AIRTAC, Series: SUJ
AirTAC SUJ Adjustable Stroke Cylinder SUJ100X110-50 Technical Details
- Full model designation: SUJ100X110-50
- Cylinder type: Double-acting adjustable stroke
- Bore size: 100mm (ISO 6432 standard)
- Max stroke: 110mm (mechanically adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (optional MF1/MF2 front flange)
- Port size: Rc1/4 (NPT1/4 optional)
- Ambient temperature: -20℃ to 80℃
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination seals
- Weight: 3.2kg ±5% (without accessories)
- Dimensions:
- Extended length: 273mm
- Retracted length: 163mm
- Body diameter: Φ112mm
- Mounting hole spacing: 125mm (center-to-center)
- IP rating: IP54 (standard seals)
- Lubrication: Pre-lubricated (Oil-free operation possible)
Precision stroke-adjustable cylinder featuring dual locking nuts for position fixation, designed for applications requiring variable stroke control without disassembly. The dual-cushion design minimizes end-impact noise (<65dB) while maintaining positioning accuracy of ±0.5mm. Compatible with auto-switching sensors (separately ordered).
Industrial Applications:
- Variable height positioning in assembly jigs
- Material handling with adjustable clamping force
- Packaging line product height compensation
- Plastic injection mold core-pulling mechanisms
- Test equipment with multi-stage positioning
Operation guidance:
Always loosen both lock nuts before stroke adjustment. After setting desired stroke length,
tighten nuts sequentially (inner nut first) to 3.5±0.5 N·m torque. Lubricate adjustment threads
monthly with ISO VG32 hydraulic oil.
Critical note:
Avoid side-load forces exceeding 150N. Use floating joints when lateral
misalignment exceeds 0.5°. Maximum lateral play tolerance: ±1.2° angular deflection.
| Property | Property Value |
|---|---|
| sku | SUJ100X110-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 110mm |
