Airtac 2-Way Solenoid Valve 2W150-15-F
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W150-15-F Solenoid Valve Specifications
- Model: 2W150-15-F
- Type: 2-position 5-way direct-acting (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 2.3
- Response time: ≤30ms (at 0.5MPa)
- Weight: 320g ±5% (excluding connector)
- Dimensions: 62mm(L) × 45mm(W) × 85mm(H)
- Seal material: HNBR rubber (heat/oil resistant variant available)
- Temperature range: -5℃ to 80℃ (with anti-freeze measures below 0℃)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Port thread depth: 10mm (minimum engagement required)
High-flow solenoid valve with dual coil redundancy, featuring brass body construction with hard-anodized aluminum end caps. Optimized for rapid cycling applications (up to 5Hz) with manual override button for emergency control. Requires 5μm filtered lubricated air (ISO 8573-1 class 4). Compatible with vacuum applications when paired with vacuum-rated seals.
- Pneumatic pressurization systems in semiconductor manufacturing
- High-speed sorting machinery (e.g., bottle cap orientation systems)
- Textile machinery shuttle controls
- Automated welding equipment gas flow switching
- Elevator door safety interlock systems
Installation protocol:
Mount with vibration-damping brackets in high-frequency applications.
Maintain ≥20mm clearance from adjacent components for heat dissipation.
Lubricate sliding parts with ISO VG32 turbine oil during maintenance.
| Property | Property Value |
|---|---|
| sku | 2W150-15-F |
| Port Size | PT 1/2 |
| Flow Aperture | <15mm> |
| Coil Voltage | DC12V |
