Airtac 2KSH Fluid Control Valve 2KSH03006A
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03006A Technical Specifications
- Model: 2KSH03006A
- Type: 3-position, 5-way (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.9 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Max flow capacity: 750 L/min (ANR)
- Response time: ≤25ms (excitation), ≤35ms (de-excitation)
- Weight: 320g ±5g
- Dimensions: 72mm(L) × 40mm(W) × 85mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with intermittent operation up to 100℃)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Protection rating: IP67 (dustproof and waterproof)
- Port thread depth: 10mm (minimum engagement)
- Manual override: Built-in emergency switch
High-flow proportional control valve with dual solenoid activation, featuring precision-machined spool mechanism for stable mid-position cutoff. The aluminum alloy body with hard anodized coating ensures corrosion resistance in humid environments. Designed for applications requiring precise directional control and position holding.
- Semiconductor wafer handling robotics
- Plastic injection molding machine clamp control
- Automated food processing conveyor systems
- Lithium battery production line actuators
- Automotive assembly line pneumatic grippers
Installation guidelines:
Use M5 mounting screws with 0.5Nm torque limit. Maintain 20mm clearance
below valve for heat dissipation. Lubricate with ISO VG32 turbine oil
if operating below -5℃. Requires 5μm filtration with auto-drain.
| Property | Property Value |
|---|---|
| sku | 2KSH03006A |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
