Airtac 2KSH Fluid Control Valve 2KSH03006EI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03006EI Specifications
- Model: 2KSH03006EI
- Type: 3-position, 5-way closed center (pneumatic pilot operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 0.35 kg (approx. 0.77 lbs)
- Dimensions: 72mm(L) × 42mm(W) × 45mm(H)
- Seal material: FKM (Fluorocarbon Rubber) for high chemical resistance
- Temperature range: -10℃ to 80℃ (14℉ to 176℉)
- Flow rate: 750 NL/min (at 0.5 MPa)
- Response time: ≤50 ms (at rated voltage)
- Protection rating: IP67 (dust-tight and protected against temporary immersion)
- Port thread depth: 12mm (with O-ring seal)
High-flow proportional control valve with precision spool design, optimized for industrial automation systems requiring mid-pressure regulation. Features corrosion-resistant aluminum alloy body with hard anodized treatment and integrated silencer. Compatible with ISO 15407-1 standards, includes manual override for emergency operation.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine actuators
- Food processing pneumatic systems (NSF-certified versions available)
- Semiconductor manufacturing equipment
- Test bench pressure regulation systems
Installation note:
Mount in vibration-free environments with proper tube support. Use 5μm filtered
dry air with lubricator (ISO 8573-1 class 4.4.2). For horizontal mounting,
install exhaust port downward to prevent condensate accumulation.
| Property | Property Value |
|---|---|
| sku | 2KSH03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
