Airtac 2KSH Fluid Control Valve 2KSH03008E
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03008E Technical Specifications
- Model: 2KSH03008E
- Type: 3-position, 5-way closed center (Double solenoid)
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤25ms (exhaust to actuation)
- Body material: Aluminum alloy (hard anodized)
- Seal material: Heat-resistant NBR (-20℃ to 120℃)
- Weight: 480g ±2% (including coil)
- Dimensions: 60mm(L) × 34mm(W) × 98mm(H)
- Port thread depth: 10.5mm (minimum engagement)
- Protection rating: IP67 (coil), IP40 (valve body)
- Service life: ≥10 million cycles (under rated conditions)
High-flow proportional control valve with dual solenoid operation, featuring a center-block design for precise mid-position control. The hard-coated aluminum construction ensures corrosion resistance in humid environments. Integrated surge suppression protects against voltage spikes. Requires 5μm filtered dry air (dew point -20℃ below ambient).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with position hold requirements
- Semiconductor wafer handling robotics
- Hydraulic system pilot stage controls
Installation guidelines:
Mount with vibration-damping pads in high-shock environments.
Maintain 20mm clearance below valve for exhaust heat dissipation.
Use M3×8 stainless screws (1.2-1.5N·m torque) for panel mounting.
Critical note:
Do NOT use silicone-based lubricants - compatible only with
phosphate ester-based additives. Maximum allowable instantaneous
current: 1.2A (DC)/0.8A (AC).
| Property | Property Value |
|---|---|
| sku | 2KSH03008E |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
