Airtac 2KSH Fluid Control Valve 2KSH03008FI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH03008FI Fluid Control Valve Technical Details
- Model: 2KSH03008FI
- Type: 3-position, 5-way closed center (pilot-operated)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 NL/min (ANR, at 0.5 MPa)
- Body material: Die-cast aluminum alloy (anodized finish)
- Seal compounds: HNBR/Nitrile rubber (standard), optional FKM/Viton
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Response time: ≤50ms (at rated voltage)
- Protection class: IP67 (dust/water resistant)
- Weight: 320g ±5% (excluding accessories)
- Dimensions: 56mm(W) × 40mm(H) × 125mm(L)
High-cycle fluid control valve with precision-machined spool design, optimized for directional control in pneumatic systems. Features dual-pressure operation capability and integrated silencer. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particle size, -20℃ pressure dew point).
- Automated assembly line clamping mechanisms
- Plastic injection molding machine actuators
- Semiconductor wafer handling robotics
- CNC tool changers and spindle locks
- Bottle filling/capping machine sequencing
Maintenance protocol:
Lubricate spool shaft quarterly with ISO VG32 turbine oil.
Avoid parallel mounting of multiple valves without 15mm spacing for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2KSH03008FI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
