Airtac 2KSH Fluid Control Valve 2KSH05010EI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH05010EI Fluid Control Valve Technical Details
- Model: 2KSH05010EI
- Type: 5-port 3-position closed center (pilot-operated)
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%)
- Max flow rate: 1,200 NL/min (ANR)
- Weight: 680g ±5% (with accessories)
- Dimensions: 72mm(L) × 48mm(W) × 106mm(H)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤50ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with closed-center configuration, featuring anti-vibration coil design and surge protection circuitry. The aluminum alloy body with hard anodizing treatment ensures durability in humid environments. Requires 5μm filtered air and 0.1W3 grade lubricator when used in high-cycle applications (>500,000 operations).
- Industrial robotic end-effector control systems
- Beverage filling line pressure regulation
- Lithium battery production equipment
- Plastic injection molding machines
- Automated test bench sequencing
Installation protocol:
Mount with M5 screws (max torque 2.5N·m) on ISO 6432-compliant manifolds.
Maintain ≥20mm clearance below valve for service access. Perform manual
override test before initial commissioning.
| Property | Property Value |
|---|---|
| sku | 2KSH05010EI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
