Airtac 2KSH Fluid Control Valve 2KSH05010FI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH05010FI Technical Details
- Model: 2KSH05010FI
- Type: 2-position 5-way pilot-operated solenoid valve
- Port configuration: 1/4" BSPP (G1/4)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 L/min (Cv=1.3 at 0.5MPa)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile)
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Response time: ≤15ms (at rated voltage)
- Duty cycle: 100% continuous operation
- Protection class: IP67 (dust/water resistant)
- Weight: 480g ±5% (without connectors)
- Dimensions: 58mm(W) × 45mm(H) × 128mm(L)
- Port thread depth: 12mm (internal)
- Max leakage: ≤0.3 NL/min (at 0.5MPa)
High-flow proportional control valve with integrated silencer, designed for precision fluid regulation in industrial automation systems. Features dual-coil latching mechanism for energy efficiency and failsafe position memory. The corrosion-resistant construction includes a hardened spool guide for extended cycle life (≥50 million operations). Requires 5μm filtered air/liquid with ISO 8573-1:2010 Class 3 purity standards.
- Beverage filling line pressure sequencing
- Semiconductor wafer handling vacuum systems
- Hydraulic press clutch/brake control
- Wastewater treatment plant pneumatic actuators
- Textile machinery tension control systems
Installation protocol:
Mount horizontally with arrow aligned to flow direction. Use flexible tubing
with 10mm vibration buffer loops. Perform 50-100 test cycles before full load
operation. Lubricate spool monthly with ISO VG32-grade oil if used with dry media.
| Property | Property Value |
|---|---|
| sku | 2KSH05010FI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
