Airtac 2KWH Fluid Solenoid Valve 2KWH03006B
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03006B Fluid Solenoid Valve Technical Details
- Model: 2KWH03006B
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (ISO228 standard)
- Operating pressure range: 0.02–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Fluid temperature: -5℃ to 80℃ (water/oil), -5℃ to 60℃ (air)
- Seal materials: FKM (Viton) for aggressive fluids, NBR standard
- Protection class: IP67 (water/dust resistance)
- Response time: ≤30ms (open/close cycle)
- Flow rate: 120L/min (air @0.5MPa)
- Weight: 320g ±5% (with coil)
- Dimensions: 54mm(L) × 42mm(W) × 73mm(H)
- Port thread depth: 12mm (male threads)
- Certifications: RoHS compliant, ISO 9001:2015
High-flow fluid control valve with corrosion-resistant brass body and epoxy-coated coil housing. Features zero-pressure differential activation capability for low-pressure systems (≥0.02MPa). Dual-seal design prevents cross-port leakage during de-energized state. Compatible with water, compressed air, light oils (ISO VG32 or lower), and non-corrosive gases.
- Industrial chillers and cooling loop control
- Automated chemical dosing systems (acid/alkali solutions)
- Beverage production line liquid routing
- Hydraulic unit pilot stage control
- Medical sterilization equipment steam control
Operational guidance:
For viscous fluids, maintain fluid temperature above 15℃ and install
downstream of 100μm filtration. Maximum 85% duty cycle recommended
for continuous operation. Use thread sealant (not Teflon tape) on ports.
| Property | Property Value |
|---|---|
| sku | 2KWH03006B |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
