Airtac 2KWH Fluid Solenoid Valve 2KWH03008AI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH03008AI Fluid Solenoid Valve Specifications
- Model: 2KWH03008AI
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 750 L/min (Cv=1.2)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: FKM fluorocarbon (standard), EPDM optional
- Body material: Aluminum alloy (anodized)
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Power consumption: 4.8W (DC24V), 5.5VA (AC220V)
- Protection rating: IP67 (coil), IP40 (valve body)
- Weight: 320g ±5% (with connector)
- Dimensions: 55mm(L) × 40mm(W) × 72mm(H)
- Port thread depth: 12mm (minimum engagement)
High-flow compact solenoid valve featuring corrosion-resistant construction and military-grade coil protection. Designed for aggressive fluid control with optional seal kits for chemical compatibility. Incorporates a manual override button for system debugging and includes built-in surge protection circuitry. Requires 10μm filtration and dry air/liquid operation (max viscosity 32cSt).
- Industrial washdown systems (food processing equipment)
- Coolant control in CNC machining centers
- Vacuum pump line switching in semiconductor manufacturing
- Hydraulic pilot stage control
- Medical gas distribution panels
- Beverage dispensing systems
Installation guidelines:
Mount with flow direction arrow aligned. For horizontal installation,
use bracket support if vibration >5G. Allow 15mm clearance around
coil for heat dissipation. Lubricate seals with silicone grease (DIETERT #732)
during maintenance.
| Property | Property Value |
|---|---|
| sku | 2KWH03008AI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
