Airtac 2L Solenoid Valve 2L03006-X0
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03006-X0 Technical Details
- Model: 2L03006-X0
- Type: 2-position 3-way direct-acting solenoid valve (Universal type)
- Port configuration: 3/2-way (Normally Closed or Normally Open selectable via rotation)
- Port size: 1/8" BSPP (G1/8)
- Operating pressure range: 0.1~1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 750 l/min (Cv=1.3)
- Seal material: High-grade NBR (Nitrile) with PTFE piston ring
- Ambient temperature: -5℃ to 60℃ (Non-freezing)
- Fluid temperature: 0℃ to 60℃
- Response time: ≤15ms (Energized), ≤20ms (De-energized)
- Protection class: IP67 (Dustproof and waterproof)
- Electrical connection: DIN43650 Form A with LED indicator
- Weight: 230g ±5g
- Dimensions: 55mm (L) × 45mm (W) × 44mm (H)
The 2L03006-X0 features a unique rotary manual override and multi-voltage compatibility, designed for high-cycle automation systems. Its brass body with hard anodized aluminum core ensures corrosion resistance in humid environments. The valve incorporates a dual-coil heat dissipation design allowing continuous duty cycle operation.
- Pneumatic clamping systems in CNC machinery
- Automatic lubrication systems for production lines
- Textile machinery thread control mechanisms
- Beverage filling equipment pressure regulation
- Semiconductor wafer handling vacuum/pressure switching
Installation guidelines:
Mount in vibration-free locations using M4 mounting screws.
Maintain minimum 20mm clearance below valve for manual override access.
Use AirTAC VG-68 pneumatic oil for lubrication if operating below -10℃.
Critical note:
Requires 5μm filtration (40μm for emergency use only).
Avoid parallel installation with high-frequency inverters (<30cm distance).
| Property | Property Value |
|---|---|
| sku | 2L03006-X0 |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
