Airtac 2L Solenoid Valve 2L03006B
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03006B Technical Details
- Model: 2L03006B
- Type: 5/2-way single solenoid (monostable)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (without connector)
- Dimensions: 80mm(L) × 40mm(W) × 60mm(H) (including ports)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE backup rings
- Temperature tolerance: -5℃ to 80℃ (no icing)
- Response time: ≤30ms (at rated voltage)
- Maximum flow rate: 150 L/min (Cv=0.45)
- Protection class: IP67 (dustproof & temporary immersion resistant)
- Lubrication: Oil-free operation (pre-lubricated for life)
- Port thread standard: ISO 228/1 (BSPP)
High-flow directional control valve engineered for demanding pneumatic systems requiring precise bidirectional cylinder movement. Features a reinforced aluminum alloy body with anodized treatment for corrosion resistance. The low-hysteresis coil design ensures stable performance under voltage fluctuations (±10% tolerance). Requires 5μm filtered compressed air with dew point -20℃ below ambient.
- Palletizing robot end-effector controls
- Plastic injection molding machine clamp units
- CNC fixture positioning systems
- Automotive welding gun actuators
- Food processing pneumatic diverters
Installation protocol:
Mount with M4 screws (recommended torque 1.2N·m). Maintain ≥15mm clearance
between valves in bank arrangements. Use shielded cables for EMI-sensitive
environments. Manual override available via push-button operator (180° rotation).
| Property | Property Value |
|---|---|
| sku | 2L03006B |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
