Airtac 2L Solenoid Valve 2L03006E
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L03006E Solenoid Valve Specifications
- Model: 2L03006E
- Type: 5/2-way double solenoid (double pilot)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (customizable)
- Weight: 380g ±5%
- Dimensions: 62mm(L) × 40mm(W) × 95mm(H)
- Flow coefficient (Cv): 1.3
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃ (150℃ peak for 1hr)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Port thread depth: 12mm (both inlet/outlet)
- Manual override: Optional paddle-type actuator
High-flow bistable solenoid valve with dual coil latching mechanism, engineered for precision directional control in industrial automation. Features hardened aluminum alloy body with anodized coating for chemical resistance. Equipped with LED position indicator and surge protection diodes. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality standard.
- Robotic arm clamping/rotating mechanisms
- Plastic injection molding machine actuators
- CNC tool changer positioning systems
- Automotive assembly line fixtures
- Food processing pneumatic circuits (oil-free version available)
Installation note:
Mount in vibration-free environment using M5 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance below valve for exhaust port maintenance. Lubricate sliding parts with ISO VG32 turbine oil during annual maintenance.
| Property | Property Value |
|---|---|
| sku | 2L03006E |
| Port Size | PT1/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
