Airtac 2L Solenoid Valve 2L03008B
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008B Technical Details
- Model: 2L03008B
- Type: 5/2-way normally closed (monostable pilot-operated)
- Port size: PT1/4 (G1/4 adaptor available)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.5 kg ±3% (including connectors)
- Dimensions: 82mm(L) × 48mm(W) × 70mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -5℃ to 80℃ (with anti-freeze measures below 0℃)
- Response time: ≤20ms (open), ≤15ms (close) at rated voltage
- Protection class: IP65 (dust-tight & water jet resistant)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Max flow rate: 1200L/min (ANR) at 0.5MPa
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with metal seal option, featuring dual-chamber pilot structure for reliable switching under pressure fluctuations. The 2L03008B's copper-free aluminum alloy body meets ISO15407-2 standards, with manual override for emergency operation. Requires 5μm filtration (40μm acceptable for non-critical applications).
- Pneumatic cylinder sequencing in packaging lines
- Clamping fixture control in CNC machining centers
- Material sorting gates in automated warehouses
- Pneumatic actuator control in textile machinery
- Pressurized vessel venting systems
Operational guidelines:
Maintain ≤85% relative humidity. Use surge protection for AC coils.
For vertical installation, exhaust port must face downward.
Lubricate with ISO VG32 pneumatic oil if air line isn't pre-lubricated.
| Property | Property Value |
|---|---|
| sku | 2L03008B |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
