Airtac 2L Solenoid Valve 2L03008BIT
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008BIT Technical Details
- Model: 2L03008BIT
- Type: 2-position 5-way (5/2) direct-acting with double solenoid
- Port size: PT1/8 (G1/8 thread standard)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Max flow rate: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: Heat-resistant NBR (Nitrile) -30℃ to 80℃
- Body material: Reinforced PBT with glass fiber
- Protection class: IP67 (dust/water resistant)
- Weight: 220g ±5g (without connectors)
- Dimensions: 52mm(L) × 34mm(W) × 78mm(H) (manual override knob excluded)
High-speed 5/2-way solenoid valve optimized for multi-cylinder sequencing in automated systems. Features dual manual override buttons for emergency control and built-in surge protection diodes. The corrosion-resistant construction withstands humid environments, while the transparent status indicator enables visual flow confirmation.
- Textile machinery double-acting cylinder control
- Plastic injection molding ejector systems
- Automated assembly line clamping devices
- Semiconductor wafer handling robots
- Food packaging air circuit switching
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use M3 mounting screws with vibration-damping washers.
Maintain 0.3m minimum clearance from high-frequency inverters.
| Property | Property Value |
|---|---|
| sku | 2L03008BIT |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
