Airtac 2L Solenoid Valve 2L03008EI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L Series Solenoid Valve 2L03008EI Technical Specifications
- Model: 2L03008EI
- Type: 2-position 3-way (3/2-way), normally closed
- Port size: PT1/8 (G1/8 optional)
- Thread standard: ISO228/1 (BSPP)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage tolerance: ±10% (Standard variants: DC12V/24V, AC110V/220V 50/60Hz)
- Response time: ≤15ms (at rated voltage)
- Flow coefficient (Cv): 0.25 (Kv: 0.22)
- Ambient temperature: -5℃ to 80℃ (with condensation prevention)
- Fluid temperature: 0℃ to 60℃
- Seal material: NBR (Nitrile), optional FKM (Viton)
- Body material: Die-cast aluminum alloy (anodized)
- Protection class: IP67 (DIN40050)
- Electrical connection: DIN43650 Form A (standard)
- Weight: 280g ±5% (without connector)
- Dimensions: 52mm(L) × 35mm(W) × 72mm(H) (excluding fittings)
High-flow 3/2-way solenoid valve optimized for rapid cycling applications. Features double-seal structure with dustproof plunger and copper-free aluminum construction for food/pharma compatibility. Integrated LED surge protection module reduces coil burnout risk. Compatible with ISO15407-1 standards.
- Automated liquid filling/purging systems
- Plastic injection molding machine ejectors
- Textile machinery tension control
- Semiconductor wafer handling robots
- Beverage dispenser valve clusters
Installation guidelines:
Mount with 15° maximum allowable tilt angle. Use 5-7Nm torque for port connections.
Install upstream 5μm filter with auto-drain. For vertical mounting, orient coil upward
to prevent debris accumulation. Lubricate with ISO VG32 turbine oil if used below -5℃.
| Property | Property Value |
|---|---|
| sku | 2L03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
