Airtac 2L Solenoid Valve 2L05015AI
2. Pilot-operated piston type normally closed 2-port 2-way solenoid valve featuring fast actuation and high flow capacity;
3. Extended pressure range compatibility, available in high-pressure (H) and standard configurations;
4. Compact, lightweight design with space-saving dimensions for easy installation and maintenance;
5. SUS304 stainless steel body construction, Class H thermal-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media including high-temperature water and saturated steam;
6. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Solenoid Valves | Brand: AIRTC | Series: 2L
AirTAC 2L05015AI Solenoid Valve Technical Details
- Model: 2L05015AI (2L Series)
- Valve type: 5-port 2-position single solenoid operated
- Port configuration: Rc1/8 (PT1/8) with M5 sub-ports
- Operation mode: Internal pilot control
- Pressure range: 0.1-1.0 MPa (14.5-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 0.18 (Kv 0.15) at 0.5 MPa
- Effective area: 18mm² (spool switching)
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Ambient temperature: -5℃ to 80℃ (with NBR seals)
- Weight: 280g ±5% (including coil)
- Dimensions: 54mm(L) × 34mm(W) × 69mm(H)
- Seal materials: Standard=NBR, optional=FKM
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 9.5mm (main ports), 7mm (pilot ports)
High-speed directional control valve featuring aluminum alloy body with hard anodized treatment for corrosion resistance. The 2L05015AI model employs a precision-machined spool structure ensuring ≤0.1ms leakage rate at maximum pressure. Designed for applications requiring rapid cycling (tested to 1 million operations), with shock-resistant coil construction using Class H insulation (180℃ rating). Requires filtered air (≤50μm particles) with lubricator recommended for optimal service life.
- Pneumatic cylinder sequencing in SMT equipment
- Clamping mechanisms for injection molding machines
- Textile machinery thread control systems
- Automated sorting line diverters
- Beverage filling station actuators
Installation guidelines:
Mount with 0.5-1.5Nm torque using M5 mounting screws. Maintain ≥20mm
clearance below valve for exhaust airflow. For horizontal mounting,
install exhaust silencers vertically downward. Pre-charge pilot line
with 0.3MPa air before initial activation.
| Property | Property Value |
|---|---|
| sku | 2L05015AI |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
