Airtac 2LH Fluid Solenoid Valve 2LH03006A
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH03006A Fluid Solenoid Valve Specifications
- Model: 2LH03006A
- Type: 3-position, 5-way (double solenoid, spring return)
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow rate: 850 l/min (ANR) at 0.5 MPa
- Weight: 480g ±3% (with coil)
- Dimensions: 58mm(L) × 48mm(W) × 81mm(H) (body only)
- Port spacing: 18mm (between centers)
- Seal material: FKM/Viton (standard), optional EPDM or NBR
- Temperature range: -10℃ to 80℃ (FKM seals), -20℃ to 60℃ (NBR seals)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤30ms (exhaust to full flow)
- Protection rating: IP67 (coil), IP40 (valve body)
- Mounting: ISO 5599-1 standard sub-base compatible
High-flow proportional control valve with dual-coil redundancy, featuring aluminum alloy anodized body and brass core components. Optimized for viscous fluids and high-cycle applications (≥10 million operations). Includes manual override and position indicator. Requires 25μm filtration with oil mist lubrication (ISO VG32 recommended).
- Hydraulic test bench sequencing
- Coolant flow control in CNC machining centers
- Automated lubrication systems
- Food-grade pneumatic conveying (with EPDM seals)
- Plastic injection molding machine actuators
- Semiconductor wafer handling robotics
Installation protocol:
Mount with vibration-damping gaskets when used in mobile equipment.
Maintain minimum 2x port diameter clearance downstream.
For vertical mounting, position coil(s) horizontally to prevent debris accumulation.
Compatibility note:
Not suitable for glycol-based fluids or phosphate ester hydraulic oils.
Maximum viscosity: 320 cSt. Always bleed residual pressure before disassembly.
| Property | Property Value |
|---|---|
| sku | 2LH03006A |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
