Airtac 2LH Fluid Solenoid Valve 2LH03008C
2、Wide operating pressure range, available in High-Pressure (H) Type and Standard Type configurations;
3、Compact structure with minimized dimensions, lightweight design, and tool-free assembly for maintenance convenience;
4、SUS304 stainless steel valve body construction. Features H-class heat-resistant coil insulation and PTFE (Teflon®) seals, ensuring compatibility with multiple media types including high-temperature water and saturated steam applications;
5、IP65-rated coil protection with wiring options: Direct Lead Wire or DIN Connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2LH
AirTAC 2LH Series Fluid Solenoid Valve 2LH03008C Technical Details
- Model: 2LH03008C (Industrial Fluid Control Edition)
- Valve type: 2-position 3-way normally closed (direct-acting)
- Fluid compatibility: Water, light oils, air (non-lubricated)
- Port connection: PT3/8 (BSPP thread) with metal-to-metal seal
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 30 L/min (water at 0.5 MPa)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 4.8W (DC24V), 5.5VA (AC220V)
- Seal materials: FKM (Fluorocarbon) for chemical resistance
- Body material: Brass with nickel plating
- Ambient temperature: -10℃ to 80℃ (non-freezing)
- Response time: ≤15ms (open/close cycle)
- Protection class: IP67 (submersible design)
- Weight: 850g ±3% (including coil)
- Dimensions: 100mm(L) × 60mm(W) × 80mm(H)
High-flow fluid control valve engineered for aggressive media handling, featuring a reinforced anti-clogging plunger system. The copper-free construction meets RoHS3 compliance, with a unique pressure-balancing chamber design enabling stable operation under pulsating flows. Requires 100μm filtration upstream.
- Coolant circulation systems in CNC machining centers
- Chemical dosing systems with pH neutralization processes
- High-cycle car wash equipment water control
- Hydroponic nutrient solution management
- Mobile hydraulic oil circuits in construction machinery
Installation protocol:
Mount horizontally with arrow aligned to flow direction.
Bleed air pockets during liquid system commissioning.
Minimum 500-hour maintenance interval for diaphragm inspection
when handling abrasive fluids.
| Property | Property Value |
|---|---|
| sku | 2LH03008C |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
