Airtac 2S Fluid Control Valve 2S05010C
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05010C Fluid Control Valve Specifications
- Model: 2S05010C
- Type: 5/2-way single solenoid pilot-operated (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Weight: 420g ±5% (without connector)
- Dimensions: 80mm(L) × 40mm(W) × 70mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Response time: ≤20ms (at rated voltage)
- Flow value: Cv=0.6 / Kv=600 L/min (ΔP=0.1MPa)
- Protection rating: IP67 (dust-tight & temporary immersion)
- Lubrication: Required (ISO VG32 turbine oil recommended)
High-flow directional control valve with double-wall epoxy coating for corrosion resistance. Features manual override button for system debugging and emergency operation. Optimized spool design reduces switching hysteresis by 30% compared to previous generation models. Requires 5μm filtration and automatic drain maintenance.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- Food packaging cylinder sequencing systems
- Pneumatic gripper control in robotics
- Industrial vacuum generator switching
Installation note:
Mount horizontally (±15° tolerance) with vibration damping pads.
Maintain 1.5x port diameter clearance for tubing connections.
Pre-charge system with 0.05MPa pressure before initial activation.
| Property | Property Value |
|---|---|
| sku | 2S05010C |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
