Airtac 2S Fluid Control Valve 2S05010CI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05010CI Fluid Control Valve Technical Details
- Model: 2S05010CI
- Type: 5-port 2-position (5/2-way) pneumatic directional valve
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.2–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Maximum flow rate: 750 L/min (ANR)
- Body material: Reinforced PBT resin with glass fiber
- Seal material: Heat-resistant NBR (Nitrile)
- Ambient temperature range: -5℃ to 60℃ (non-freezing)
- Response time: ≤30ms (at 0.5MPa)
- Protection class: IP67 (dust/water resistant)
- Weight: 320g ±5% (including connectors)
- Dimensions: 58mm(L) × 34mm(W) × 78mm(H) (excluding mounting tabs)
- Port thread depth: 9mm (minimum engagement)
High-flow compact directional valve with dual-pressure operation capability. Features integrated silencer and shock-absorbing spool design for reduced noise levels (≤65dB). The coil is vacuum-potted for vibration resistance and includes surge protection circuitry. Requires ISO 8573-1 class 3 lubricated or non-lubricated air.
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- Textile machinery cylinder control
- Food processing pneumatic actuators (FDA-compliant variants available)
- Semiconductor wafer handling robots
Installation guidelines:
Mount with M4 screws (recommended torque 1.2N·m). Maintain minimum 15mm
clearance below valve for exhaust airflow. Perform monthly manual cycling
in high-humidity environments. Use thread sealant only on male ports.
| Property | Property Value |
|---|---|
| sku | 2S05010CI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
