Airtac 2S Fluid Control Valve 2S05010E
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S Series Fluid Control Valve 2S05010E Specifications
- Model: 2S05010E
- Type: 2-position 5-port direct-acting solenoid valve
- Port configuration: 5/2-way (double solenoid)
- Port size: G1/8 (ISO228 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0.1–1.0 MPa
- Maximum flow rate: 850 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 500g ±3% (with connectors)
- Dimensions: 70mm(L) × 40mm(W) × 30mm(H) (excluding mounting brackets)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced chemical resistance
- Temperature range: -10℃ to 80℃ (with silicone grease lubrication below 0℃)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (dust tight and protected against temporary immersion)
- Cycle life: ≥10 million operations
High-flow proportional control valve featuring dual-coil latching design for energy efficiency. The aluminum alloy body with hard anodized treatment ensures corrosion resistance in humid environments. Integrated LED status indicator and manual override button simplify maintenance. Requires 5μm filtered compressed air with max 1mg/m³ oil content.
- Automated production line clamping systems
- Plastic injection molding machine actuators
- Textile machinery tension control
- Beverage filling equipment flow regulation
- Semiconductor wafer handling robots
Installation note:
Mount using M4 screws with vibration-proof washers. Maintain 20mm minimum clearance
on both sides for heat dissipation. Perform monthly cleaning of exhaust ports using
dry compressed air (≤0.3MPa).
| Property | Property Value |
|---|---|
| sku | 2S05010E |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC24V |
