Airtac 2S Fluid Control Valve 2S05010F
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05010F 2-Position 5-Port Fluid Control Valve Specifications
- Model: 2S05010F
- Type: 5/2-way monostable (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 320g ±5g
- Dimensions: 54mm(L) × 40mm(W) × 50mm(H)
- Valve body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile), optional FKM (Fluorocarbon)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Flow capacity: Cv=0.5 (at 6 bar)
- Response time: ≤20ms (at rated voltage)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
High-speed directional control valve with optimized flow paths for reduced pressure drop. Features dual-chamber sealing technology for leak-free operation and hardened stainless steel spool for extended cycle life (>10 million cycles). Compatible with ISO 15407-1 standards. Requires 5μm filtered air with lubrication not exceeding ISO VG32 grade.
- High-speed packaging machine actuators
- Automated assembly line clamping systems
- Textile machinery cylinder control
- Medical device pneumatic circuits
- Semiconductor handling equipment
Installation note:
Mount in vibration-free environment using M4 mounting screws (torque ≤1.2N·m).
Maintain 15mm clearance below valve for manifold heat dissipation.
Use thread sealant only on male ports, avoiding contamination of pilot channels.
| Property | Property Value |
|---|---|
| sku | 2S05010F |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC12V |
