Airtac 2S Fluid Control Valve 2S05015AIG
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05015AIG Fluid Control Valve Technical Details
- Model: 2S05015AIG
- Type: 5-port 3-position closed center (Pilot-operated)
- Port configuration: 5/3-way closed center
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.2–1.0 MPa
- Maximum flow rate: 850 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 0.68 kg ±2%
- Dimensions: 58mm (L) × 45mm (W) × 98mm (H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Ambient temperature range: -5℃ to 80℃ (with anti-freeze measures below 0℃)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤30ms (exhaust to center position)
- Protection rating: IP67 (dustproof & temporary immersion resistant)
- Manual override: Built-in emergency push button
High-flow proportional control valve with closed-center functionality, featuring precision-machined aluminum alloy body and brass core components. Designed for systems requiring mid-position pressure holding and rapid exhaust. Incorporates surge protection circuitry and LED status indicator. Requires 5μm filtered compressed air with oil mist (ISO8573-1 Class 4).
- Automated assembly line clamping systems
- Plastic injection molding machine sequence control
- Food processing pneumatic circuits (NSF compliant)
- Semiconductor wafer handling robotics
- Hydraulic system pilot stage control
Installation guidelines:
Mount with vibration-damping brackets in horizontal orientation.
Maintain minimum 20mm clearance around valve for heat dissipation.
Use M5x12mm stainless steel screws (torque ≤1.2N·m) for manifold mounting.
| Property | Property Value |
|---|---|
| sku | 2S05015AIG |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
