Airtac 2S Fluid Control Valve 2S05015B
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05015B Fluid Control Valve Specifications
- Model: 2S05015B
- Type: 2-position, 5-port directional control valve
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.05–0.7 MPa
- Max flow rate: 1,200 L/min (ANR)
- Voltage options: DC24V (±10%), AC220V (±10% 50/60Hz)
- Coil power: 2.2W (DC), 3.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 480g ±5% (including coil)
- Dimensions: 58mm(L) × 46mm(W) × 75mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR rubber (FDA compliant option available)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement required)
High-flow proportional control valve with integrated silencer, featuring dual-pressure operation capability. The hardened stainless steel spool ensures 2 million cycle durability. Includes manual override and position indicator. Requires 5μm filtration (25μm for emergency use). Compatible with ISO 8573-1:2010 Class 3 compressed air.
- Automated assembly line clamping systems
- Beverage filling machine pressure regulation
- Plastic injection molding machine actuators
- Wastewater treatment plant pneumatic gates
- Semiconductor cleanroom equipment
Installation note:
Mount with vibration-damping brackets in high-frequency operation environments.
Lubricate with ISO VG32 turbine oil if used in continuous duty cycles exceeding 60% ON-time.
| Property | Property Value |
|---|---|
| sku | 2S05015B |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC24V |
