Airtac 2S Fluid Control Valve 2S05015C
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S Series Fluid Control Valve 2S05015C Technical Details
- Model: 2S05015C
- Type: 3-position, 5-way closed center (Double solenoid)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Flow capacity: 750 L/min (Cv=1.3)
- Response time: ≤30ms (at 0.5MPa)
- Weight: 280g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 75mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.8W (DC24V), 3.5VA (AC220V)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
High-performance mid-sized directional control valve featuring dual electromagnetic operation with manual override capability. The hardened aluminum alloy body with chrome-plated brass core ensures durability in high-cycle industrial environments. Designed for systems requiring precise directional control with zero leakage in neutral position.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- CNC tool changer pneumatic circuits
- Food processing equipment actuators
- Lithium battery production line vacuum systems
Installation guidelines:
Mount with vibration-damping brackets in high-frequency applications.
Maintain 15mm minimum clearance for heat dissipation. Use ISO 8573-1
Class 3 compressed air with 5-50μm filtration. Lubricate quarterly
with ISO VG32 turbine oil if non-lubricated system.
Critical note:
Always install downstream pressure regulators. Avoid rapid
cycling (>5Hz) without auxiliary cooling. Maximum allowable
instantaneous current: 1.2A (DC)/0.6A (AC).
| Property | Property Value |
|---|---|
| sku | 2S05015C |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
