Airtac 2ST Fluid Control Valve 2ST03008A
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST03008A Fluid Control Valve Technical Details
- Model: 2ST03008A
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10%)
- Weight: 320g ±5g
- Dimensions: 98mm(L) × 43mm(W) × 34mm(H)
- Seal material: FKM fluorocarbon (standard), optional HNBR
- Temperature range: -10℃ to 80℃ (extended to 120℃ with HNBR seals)
- Flow capacity: 750 L/min (ANR)
- Response time: ≤30ms (at 0.5MPa)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (NPT), 10mm (G)
High-flow directional control valve with center-block function, featuring brass body construction with hard anodized aluminum solenoid housing. Designed for precision mid-stroke positioning in pneumatic systems. Includes manual override and surge suppression diodes. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Clamping/positioning in CNC machine tools
- Actuator control in automated assembly lines
- Material handling systems with safety interlocks
- Plastic injection molding machine sequences
- Textile machinery tension control mechanisms
Installation guidelines:
Mount with 15mm clearance below for tubing access. Lubricate O-rings with
silicone grease during assembly. Perform monthly manual cycling to prevent
spool sticking in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | 2ST03008A |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC220V |
