Airtac 2ST Fluid Control Valve 2ST05010B
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design featuring minimized dimensions, lightweight construction, and tool-free maintenance accessibility;
4. SUS304 stainless steel valve body with B-class thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon request - consult technical department for specifications;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2ST
AirTAC 2ST05010B Fluid Control Valve Specifications
- Model: 2ST05010B
- Type: 5-port 2-position (5/2-way) solenoid valve
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 350g ±5% (including coil)
- Dimensions: 98mm(L) × 45mm(W) × 45mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Flow capacity: 850 l/min (ANR) at 0.5MPa
- Response time: ≤15ms (at rated voltage)
- Protection rating: IP67 (coil protection)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with dual-coil latching design for energy-efficient operation. Features brass body with hard anodized aluminum sleeve for corrosion resistance. Requires 5μm filtered air with oil mist lubrication (ISO8573-1 Class 4). Compatible with ISO15407-1 standard subplates.
- Industrial automation sequencing systems
- Plastic injection molding machine actuators
- Automotive assembly line clamping devices
- High-cycle packaging machinery
- Pneumatic conveyor diverters
Installation note:
Use M5 mounting screws with 0.4-0.6Nm torque. Maintain 15mm clearance
above valve for heat dissipation. Lubricate seals with ISO VG32-grade
pneumatic oil during maintenance.
Critical parameters:
Do NOT exceed 1.2MPa burst pressure. Coil duty cycle ≤ED60% at 20℃ ambient.
Use surge suppressor for DC models in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | 2ST05010B |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | DC24V |
