Airtac 2SX Fluid Control Valve 2SX05010A
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05010A Fluid Control Valve Specifications
- Model: 2SX05010A
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.8 MPa
- Max flow rate: 700 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 205g ±5g
- Dimensions: 50mm(L) × 25mm(W) × 40mm(H)
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: 2.2W (DC24V), 3.5VA (AC220V)
- Port thread tolerance: ISO 228-1 standard
- Protection rating: IP67 (dust/water resistant)
High-speed fluid control valve with optimized flow path design, featuring brass body with electroless nickel plating for corrosion resistance. The direct-acting mechanism ensures reliable switching without minimum pressure requirement. Includes manual override button for system debugging.
- Industrial automation sequencing systems
- Beverage dispensing machine flow control
- Textile machinery pneumatic circuits
- Semiconductor wafer handling equipment
- HVAC damper actuators
- Automated test bench instrumentation
Installation guidelines:
Use PTFE tape on male threads only. Maintain 20mm clearance below valve for condensate drainage.
Lubricate with ISO VG32 turbine oil if used in high-cycle applications (>500,000 cycles/month).
| Property | Property Value |
|---|---|
| sku | 2SX05010A |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC220V |
