Airtac 2SX Fluid Control Valve 2SX05015E
2. Extensive pressure range options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced footprint, lightweight construction, and tool-free installation/maintenance;
4. SUS304 stainless steel body, B-class heat-resistant coil, standard FPM (Fluorocarbon Rubber) seals for multi-media compatibility. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SX
AirTAC 2SX05015E Fluid Control Valve Specifications
- Model: 2SX05015E
- Type: 5-port, 2-position directional control valve (monostable)
- Port size: 1/4" BSPP (G1/4)
- Operating pressure range: 0.2–1.0 MPa
- Maximum flow rate: 850 L/min (Cv=1.2)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil power: 1.8W (DC), 2.5VA (AC)
- Weight: 210g ±5% (excluding accessories)
- Dimensions: 50mm(L) × 35mm(W) × 68mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile) rubber
- Operating temperature: -10℃ to 80℃ (non-freezing)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with manual override capability, featuring optimized flow paths for reduced pressure drop. The hardened aluminum construction ensures durability in high-cycle industrial environments. Includes LED status indicator and surge protection circuitry. Requires 5μm filtration (40μm for emergency use).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changer mechanisms
- Food processing pneumatic circuits
- Semiconductor handling robotics
- Elevator brake control systems
Installation guidelines:
Mount in vibration-free locations using M4 mounting screws (max torque 1.2N·m).
Maintain minimum 15mm clearance below valve for exhaust airflow. Lubricate with ISO VG32
turbine oil if used in continuous operation above 60℃. Perform monthly manual cycling
in dusty environments.
| Property | Property Value |
|---|---|
| sku | 2SX05015E |
| Port Size | PT 1/2 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
