Airtac 2WT Extra High Flow Solenoid Valve 2WT03008CI
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT03008CI High Flow Solenoid Valve Specifications
- Model: 2WT03008CI
- Type: 3/2-way normally closed (direct-acting)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 2.2 / S-value 5.0 (Nl/min @6bar)
- Response time: ≤15ms (open/close)
- Weight: 680g ±5%
- Dimensions: 86mm(L) × 48mm(W) × 78mm(H)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -10℃ to 80℃ (with 0.1s duty cycle cooling)
- Power consumption: ≤4.5W (DC) / ≤5.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 13mm (minimum engagement)
High-torque solenoid valve optimized for industrial-scale pneumatic systems requiring rapid cycling and large air volume handling. Features dual-coil heat dissipation design and brass core construction for 500,000+ cycle durability. Requires 25μm filtered dry air with ISO 8573-1:2010 Class 3.2.3 quality.
- Plastic injection molding machine clamp units
- Automotive tire assembly line actuators
- High-speed bottle blowing systems
- Foundry air knife moisture removal
- Lithium battery production vacuum handling
Installation protocol:
Mount horizontally with manifold brackets (M5x0.8 screws, 2.5Nm torque limit).
Maintain 50mm clearance below valve for condensate drainage. Use copper-free
anti-seize compound on threads for maintenance access.
| Property | Property Value |
|---|---|
| sku | 2WT03008CI |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC 110V |
