Airtac 2WT Extra High Flow Solenoid Valve 2WT03008EI
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT Series High Flow Solenoid Valve 2WT03008EI Technical Details
- Model: 2WT03008EI
- Type: 5/3-way direct-acting with central exhaust
- Port size: G3/8 (DN10 equivalent)
- Max flow rate: 6,000 L/min (Cv=13.5)
- Operating pressure: 0.1–1.0 MPa
- Voltage variants: DC24V (±10%), AC110V/120V (50/60Hz), AC220V/240V (50/60Hz)
- Weight: 2.8 kg (with coil)
- Dimensions: 150mm(L) × 65mm(W) × 98mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal compounds: HNBR/FKM (fluorocarbon) hybrid seals
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Response time: ≤30ms (at 0.5MPa)
- Protection class: IP67 (coil)/IP40 (valve body)
- Mounting style: ISO 15407-1 compliant sub-base
Industrial-grade high-flow solenoid valve engineered for heavy-duty pneumatic systems requiring rapid cycling and large volume control. Features triple-coil heat dissipation design with integrated surge protection diodes. Requires 5μm filtration (ISO 8573-1 class 4) and lubrication-free air (N2 permitted).
- Plastic injection molding machine clamp units
- Automotive tire curing press air circuits
- High-speed packaging line diverters
- Steel mill cylinder banks (actuator control)
- Semiconductor wafer handling vacuum/pressure switches
Installation protocol:
Mount horizontally with exhaust ports downward. Use vibration-damping brackets
for high-cycle applications (>1M operations/month). Allow 20mm side clearance
for heat dissipation. Lubricate sliding parts with ISO VG32 pneumatic oil
during quarterly maintenance.
| Property | Property Value |
|---|---|
| sku | 2WT03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <6mm> |
| Coil Voltage | AC24V |
