Airtac 2WT Extra High Flow Solenoid Valve 2WT050-10-A
2. Wide operating pressure range with selectable configurations: Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T);
3. Compact design, lightweight construction, and easy installation/maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (FKM) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection and wiring options: Direct lead-wire or DIN connector.
Category: Solenoid Valves, Brand: AirTAC, Series: 2WT
AirTAC 2WT050-10-A High Flow Solenoid Valve Specifications
- Model: 2WT050-10-A
- Type: 5-port 3-position (closed center type)
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.1–1.0 MPa
- Max flow rate: 5000 L/min (ANR)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 2.8 kg ±5%
- Dimensions: 196mm(L) × 72mm(W) × 122mm(H)
- Seal material: Heat-resistant NBR (nitrile rubber)
- Temperature range: -5℃ to 80℃ (with 20% margin for intermittent use)
- Power consumption: 4.5W (DC24V), 5.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Flow coefficient (Cv): 13.5
- Lubrication: Pre-lubricated (ISO VG32 compatible)
Industrial-grade high-flow solenoid valve designed for demanding pneumatic systems requiring rapid response and massive airflow. Features anodized aluminum body with stainless steel core components for corrosion resistance. Includes manual override and position indicator. Requires 5μm filtered/dried air with 1-10mg/m³ oil mist (ISO 8573-1 class 4).
- Automotive stamping press clutches
- Plastic injection molding machine actuators
- High-speed packaging line diverters
- Foundry equipment air blast systems
- Railway brake simulation rigs
- Industrial vacuum pump controls
Installation notes:1. Mount horizontally with coil facing upward
2. Install upstream filter-regulator (F.R.L. unit) within 1m
3. Allow 50mm clearance around valve body for heat dissipation
4. Use anti-vibration mount in high-shock environments
5. Lubricate every 10M cycles under continuous operation
| Property | Property Value |
|---|---|
| sku | 2WT050-10-A |
| Port Size | PT3/8 |
| Flow Aperture | <10mm> |
| Coil Voltage | AC220V |
