Airtac 2WX Fluid Solenoid Valve 2WX03008F
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX03008F Fluid Solenoid Valve Technical Details
- Model: 2WX03008F
- Type: 2-position 3-way direct-acting (monostable)
- Port configuration: IN/OUT/EXH with PT1/8 (G1/8 optional)
- Effective orifice: Ø2.0mm
- Flow coefficient (Cv): 0.45
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤15ms (open), ≤20ms (close)
- Body material: Anodized aluminum alloy
- Seal materials: NBR (standard), optional VITON/FKM
- Ambient temperature: -5℃ to 60℃ (with humidity <85% RH)
- Protection class: IP67 (dust/water resistant)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Weight: 220g ±5g (without connector)
- Dimensions: 54mm(L) × 40mm(W) × 76mm(H)
High-flow compact solenoid valve featuring low hysteresis and bubble-tight shutoff. Designed for compressed air systems requiring rapid cycling (up to 5Hz continuous operation). The hard-anodized body resists chemical corrosion and mechanical wear. Compatible with ISO 8573-1:2010 [3:4:3] class compressed air.
- Pneumatic cylinder sequencing in semiconductor wafer handling robots
- Vacuum cup control systems for glass panel manufacturing
- Precision gas mixing stations for food packaging lines
- Mobile hydraulic test bench pressure regulation
- Automotive assembly line tooling actuators
Operational guidelines:
Install with flow arrow aligned to piping direction. Use 5μm filter regulator with auto-drain.
For vertical mounting, position coil upward. Lubricate every 5M cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 2WX03008F |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC12V |
