Airtac 2WX Fluid Solenoid Valve 2WX05010B
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05010B Fluid Solenoid Valve Specifications
- Model: 2WX05010B
- Type: 2-position, 2-way normally closed (direct-acting)
- Port size: PT1/8 (G1/8 optional)
- Thread standard: BSPP/BSPT/NPT available
- Operating pressure: 0.1–0.7 MPa (14.5–101.5 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W max | AC: 3.5VA max
- Flow coefficient (Cv): 0.12
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: NBR (Nitrile) standard | Optional FKM (Viton) for high temp
- Temperature range: -5℃ to 80℃ (NBR) | -5℃ to 150℃ (FKM option)
- Body material: Brass with nickel plating
- Protection rating: IP67 (dust/water resistant)
- Weight: 210g ±5g (without connector)
- Dimensions: 54mm(L) × 36mm(W) × 38mm(H)
- Port spacing: 12mm between ports
High-response solenoid valve with compact cylindrical design, optimized for precise fluid control in both air and neutral liquid applications. Features wear-resistant guide structure and gold-plated terminals for stable conductivity. Requires 25μm filtration (40μm max) with recommended 0.1-0.3 MPa lubrication pressure.
- Pneumatic cylinder control in automated assembly lines
- Medical device gas flow regulation (oxygen concentrators, analyzers)
- Beverage dispensing systems with CO₂ control
- Industrial cleaning equipment water pulse control
- Laboratory vacuum/pressure switching devices
Installation guidelines:
Mount horizontally with coil facing upward. Allow minimum 30mm clearance
below valve for connector access. Use anti-vibration washers in high-frequency
applications (>5Hz switching). Lubricate with ISO VG32 turbine oil if operating
below -5℃.
| Property | Property Value |
|---|---|
| sku | 2WX05010B |
| Port Size | PT3/8 |
| Flow Aperture | <3mm> |
| Coil Voltage | DC24V |
