Airtac 2WX Fluid Solenoid Valve 2WX05015B
2. Wide pressure range adaptability with selectable variants: Ultra-high pressure (X), High pressure (H), Standard, High flow (L), and Extra-high flow (T);
3. Compact design with minimal footprint, lightweight construction, and simplified installation/maintenance;
4. Brass valve body with B-class thermal-rated coils. Standard FPMF (Fluorine Rubber) seals ensure multi-media compatibility. Custom seal materials available upon request – consult our technical department;
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2WX
AirTAC 2WX05015B Fluid Solenoid Valve Specifications
- Model: 2WX05015B
- Type: 2-position 5-way direct acting (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Thread type: Parallel (BSPP)
- Operating pressure: 0.1–1.0 MPa
- Proof pressure: 1.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Power consumption: 1.8W (DC), 3.5VA (AC)
- Response time: ≤15ms (exhaust to pilot)
- Flow coefficient (Cv): 1.2
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced chemical resistance
- Temperature range: -10℃ to 80℃ (with 0℃ dew point)
- Protection rating: IP67 (dustproof and temporary immersion resistant)
- Housing material: Reinforced PBT with UL94 V-0 flame rating
- Weight: 215g ±5g
- Dimensions: 55mm(L) × 40mm(W) × 72mm(H) (excluding fittings)
- Port spacing: 18mm between centerlines
High-flow 5/2-way valve with dual coil configuration for bi-stable control applications. Features metal piston construction with anti-stiction surface treatment and gold-plated terminals for reliable switching. Designed for 3 million cycle durability under rated conditions. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Pneumatic cylinder sequencing in assembly lines
- Rotary actuator control in packaging machinery
- Clamping/unclamping systems in CNC fixtures
- Air-driven conveyor diverters
- Automated test equipment with position hold requirements
Installation guidelines:
Mount in vibration-free locations using M4 screws (max torque 1.2N·m).
Maintain 20mm clearance below exhaust ports for silencer attachment.
For horizontal mounting, orient coils vertically upward.
Pre-charge system with lubricated air extends service intervals.
